Programming Instructions
Hz Key Chain Transmitters 2 and 4 channels
®
PROGRAMMING
1) Program the motor using a
standard transmitter as per the
quick reference guide
3) Touch the programming
contact on the back of the Key
Chain Transmitter with a metal
conductor (paper clip). The LED
on the front will start to flash
Paper
Clip
Programming
Contact
Repeat steps 1 through 4 for other buttons to other motors if desired.
Note: Only program one motor per button. The 2 channel key chain can be used
to control 2 motors maximum and the 4 channel can control 4 motors maximum
Flashing LED
2) Press the programming button
on the standard transmitter until
the motor jogs up/down
4) Press the desired front button
while the LED is still flashing. The
motor will jog. This button will now
control the motor.
Hz Key Chain Trans
Read all instructions carefully before use.
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for Simu TSA 4
Summary of Contents for Simu TSA 4
- Page 1 Programming Instructions Hz Key Chain Trans Read all instructions carefully before use. Hz Key Chain Transmitters 2 and 4 channels ® PROGRAMMING 1) Program the motor using a 2) Press the programming button standard transmitter as per the on the standard transmitter until quick reference guide the motor jogs up/down 4) Press the desired front button...
-
Page 2: Programming Instructions
LOCKING/UNLOCKING TSA 4 A - Enabling the locking function - Once a locking code has been entered the TSA 4 will automatically lock the buttons after 2 minutes without a command to prevent unintended operation. The buttons can be unlocked as per section B.
