Audiovox PAV1510DTV Bulletin

Tech Bulletin Number: MVTB-102104 REV. A
Date: October 21, 2004
Product Part Number: Audiovox PAV1510DTV and Jensen VM9510
Product Description: AM/FM/DVD/CD/MP3/TV Receiver with 7" Wide Screen Display
Situation/Problem: On certain power amplifiers the remote amp turn on line does not turn off
externally connected power amplifier(s) when the radio is turned off and the vehicle is running.
Solution: Add a 4.7kohm resistor from the remote shutoff line to ground either at the amplifier or at the
radio (see figure 1 below.
Remote Turn On Wire (Blue)
PAV151DTV
External Power Amplifier
4.7 kohm
VM9510

Figure 1

For additional information or installation help, call 1-800-225-6074
Monday through Friday: 8:30 AM to 7:00 PM EST, Saturdays: 9:00 AM to 5:00 PM EST
