- Page 1 MM801 8.4” LCD OVERHEAD MONITOR ON OFF AUTO POWER M EN U/ DOWN ENTER OPERATION MANUAL...
-
Page 2: Important Notice
In the interest of safety, the MM801 should never be installed where it will be visible, directly or indirectly, by the operator of the motor vehicle. -
Page 3: Power On/Off
Congratulations on your purchase of the Movies 2 Go MM801 drop-down Video Monitor. The MM801 has been designed to give you and your family many years of video entertainment in the mobile environment. Please read the directions that follow to familiarize yourself with the product and to ensure that you obtain the best results from your equipment. -
Page 4: Front Panel Features
FRONT PANEL FEATURES ON OFF AUTO POWER MENU/ ENTER MM801... -
Page 5: Front Panel
FRONT PANEL 1. Infrared Transmitter – Used to transmit audio to wireless headphones. 2. Remote Sensor – For Remote Control to operation of the MM801. 3. Dome Lights – Provide additional interior illumination. 4. Three Position Dome Light Switch •... - Page 6 The internal friction detent will hold the screen in position while the system is in use. 2. Press the power button to turn on the MM801. 3. After the unit is turned ON and begins to display a picture, adjust the viewing angle by pivoting the screen to optimize the picture quality.
-
Page 7: Operation
OPERATION OVERHEAD DOME LIGHTS The Dome Lights integrated into the MM801 are controlled by a three position slide switch. Sliding the switch to the ON position will turn the lights ON. The OFF position will prevent the lights from turning ON with the vehicle’s interior lighting, and the auto position will allow the lights to turn ON and OFF with the vehicle’s... -
Page 8: Remote Control Sensor
REMOTE CONTROL SENSOR The MM801 incorporates an infrared sensor will relay signals from the remote control to allow a source connected to the AV1 input to be controlled simply by pointing its remote control at the remote sensor eye. This provides control of source equipment such as a Video Cassette Player or DVD Player. - Page 9 REMOTE CONTROL UNIT BUTTONS CONTROLS LCD : Power On / Off Button for the MM801 monitor SOURCE VCP : Power On / Off Button for an Optional Audiovox VCP MENU/ ENTER SOURCE : Button for selection of AV1 and AUX MENU/ENTER Button –...
-
Page 10: Picture Adjustment
COLOR PICTURE PICTURE TINT TINT SOURCE SOURCE RESET RESET DISPLAY OFF DISPLAY OFF BRIGHTNESS BRIGHTNESS Press UP button To brighten the picture Increases the picture contrast for vivid color To increase the color intensity Inceases the redish skin tones MM801... -
Page 11: Source Select
To exit the main menu, highlight DISPLAY OFF and press MENU button to enter, the menu will disappear. NOTE: The menu will also disappear from the screen automatically if you do not press any button within five seconds. MM801 MENU MENU SOURCE... -
Page 12: Optional Accessories
AV adapter cable input. To play the AUX source, turn the MM801 ON and press the Menu button, the main menu will appear. Select SOURCE and then press the menu/enter button. -
Page 13: Troubleshooting
* The source can also be selected by pressing the source button on the remote control.Turn the source component on with its power button or remote control. The MM801 is now ready to play the audio and video signals from the source connected to AUX input. -
Page 14: Specifications
SPECIFICATIONS LCD Backlighting Edge Light Tube Resolution 1440 X 234 Pixels 336,960 Operation Temperature 0 - 50º C Storage Temperature -20 - 70º C Expected Backlight life 10,000 Hours Video Display System NTSC / PAL MM801... -
Page 15: 12 Month Limited Warranty
AEC (the Company) warrants to the original retail purchaser of this product that should this product or any part thereof, under normal use and conditions, be proven defective in material or workmanship within 12 months from the date of original purchase, such defect(s) will be repaired or replaced with reconditioned product (at the Company's option) without charge for parts and repair labor.
