DataMan
370 Series
Quick Reference Guide
2020 October 05
Revision: 6.2.1.1

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the DataMan 370 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Cognex DataMan 370 Series

Summary of Contents for Cognex DataMan 370 Series

  • Page 1 ® DataMan 370 Series Quick Reference Guide 2020 October 05 Revision: 6.2.1.1...
  • Page 2 (ESD), power surges, or other irregularities in the power supply. Do not install Cognex products where they are exposed to environmental hazards such as excessive heat, dust, moisture, humidity, impact, vibration, corrosive substances, flammable substances, or static electricity.

  • Page 3: Product Overview

    Ensure that the cable bend radius begins at least six inches from the connector. Cable shielding can be degraded or cables can be damaged or wear out faster if a service loop or bend radius is tighter than 10X the cable diameter.
  • Page 4 Network Error Peak meter Tuning button Ethernet SD card slot External light control Power, I/O, and RS-232 DataMan 370 Series Accessories LENS OPTIONS AND COVERS Accessory DM374 DM375 8 mm F5.6 fixed aperture lens LEC-CFF08- F5.6 12 mm F8 fixed aperture lens...
  • Page 5 DM374 DM375 Accessory Liquid lens module and pre-focused 10.3* mm or DMLN-10LL- 10.3 mm IR** M12 lens with wrench DMLN-10LL- IR-SMT 24 mm F6 liquid lens module* DM360- LENS-24LL 24 mm F6 liquid lens module*** DMLN- C24F06-LL- 24 mm F10 liquid lens module* DMLN- C24F10-LL 10 mm F5 autofocus lens* (use with HPIT)
  • Page 6 DM374 DM375 Accessory C-Mount cover for C-Mount lenses DM300- CMCOV Short C-Mount cover for C-Mount lenses DM300- CMCOV- Extension kit DM300- DM500 C-Mount cover (use with HPIA) DM500- CMTLC- DM500 Lens cover extender DM500- LNSEXT-...
  • Page 7 DM374 DM375 Accessory Red LED HPIL, 10.3 mm lens DM360- HPIL-RE (Risk Group Red LED Exempt acc. IEC 62471, Risk Group Green LED Aimer Exempt acc. IEC 62471) Polarized red LED HPIL, ESD safe, 10.3 mm lens DM360- HPIL-RE-P (Risk Group Red LED Exempt acc. IEC 62471, Risk Group Green LED Aimer Exempt acc.
  • Page 8 DM374 DM375 Accessory Coaxial (DOAL) light CLRO-K5050G1 Spot light CLRS-P14G1 Dark-field light CLRD-D120G1 Brick light, narrow blue IVSL-ODDM-S75-470 Brick light, narrow red IVSL-ODDM-S75-625 Brick light, narrow white IVSL-ODDM-S75-WHI Bar light, wide red IVSL-YLW2X-625 Bar light, narrow red, linear polarizer IVSL-YLW2X-625P Bar light, narrow infrared IVSL-YLW2X-850 Bar light, narrow blue...
  • Page 9 DM374 DM375 Accessory LX280-series light, blue IVSL-LX280-470 LX280-series light, red IVSL-LX280-625 Bar light, red IVSL-LX800-625 Linear Polarizer Kit Case DM30X-HPIA3-LP HPIA, Red narrow DM30X-HPIA3-625 HPIA, Red wide DM30X-HPIA3-625-W HPIA, White narrow DM30X-HPIA3-WHI (Risk Group White LED low risk acc. IEC 62471) HPIA,White wide DM30X-HPIA3-WHI-W (Risk Group White LED low risk acc.
  • Page 10 DM374 DM375 Accessory HPIT, Red, wide, 10 and 16 mm lens DMLT-HPIT-RE-W (Risk Group Red LED exempt risk acc. IEC 62471) HPIT, Red, standard, 24 mm lens DMLT-HPIT-RE-S (Risk Group Red LED exempt risk acc. IEC 62471) HPIT, White, wide, 10 and 16 mm lens DMLT-HPIT-WHI-W (Risk Group White LED low risk acc.
  • Page 11 DM374 DM375 Accessory Field of view expander with mount DMA-XPAND-100 Field of view expander DMA-XPAND-150 Field of view expander DMA-XPAND-250 Field of view expander DMA-XPAND-300 OTHER Accessory DM374 DM375 Connection cable RS-232 CCB- M12xDB9Y-...
  • Page 12 Accessory DM374 DM375 Connection cable 24 V, I/O, RS-232 (y CCB- straight/angled, xx specifies length) M12x12Fy- Connection cable 24 V, I/O, RS-232 CCBL-05-01 Power and I/O breakout cable, M12-12, straight, xx CCB- specifies length: 5 m, 10 m, 15 m, PWRIO-xx CCB- angled, xx specifies length: 5 m, 10 m, 15 m...
  • Page 13 Accessory DM374 DM375 I/O extension cable, 5 m straight CKR-200- CBL-EXT Laser aimer (use with HPIA) DM300- AIMER-00 Connection module (4 or 1 camera) DMA-CCM- (xx can be US, EU, UK or JP) 4X-xx DMA-CCM- 1-xx Pivot Mounting Bracket DM100- PIVOTM-00 External heat sink DMHS-370-...
  • Page 15 Dimensions C-Mount Lens (1"-32tpi) Optical axis DataMan 370 DataMan 370 with High Power Integrated Light (HPIL)
  • Page 16 DataMan 370 with High Power Illumination Accessory (HPIA)
  • Page 17 DataMan 370 with High Power Integrated Torch (HPIT)

  • Page 18: Field Of View And Reading Distances

    Field of View and Reading Distances Note: Due to tolerances, ranges can vary by +/- 5 % from unit to unit. Distances in mm / 1D min code Distances in mm / 2D min code Device 10 mm HSLL 10 mm HSLL 6 MIL 6 MIL 8 MIL...
  • Page 19 Distances in mm / 1D min code Distances in mm / 2D min code Device 16 mm HSLL 16 mm HSLL 6 MIL 6 MIL 8 MIL 8 MIL 1125 10 MIL 10 MIL DM37x 1462 13 MIL 1006 13 MIL 1687 15 MIL 1160 15 MIL...
  • Page 20 Distances in mm / 1D min code Distances in mm / 2D min code Device 24 mm HSLL 24 mm HSLL 1029 6 MIL 6 MIL 1370 8 MIL 8 MIL 1711 10 MIL 1178 10 MIL DM37x 2223 13 MIL 1530 13 MIL 2564 15 MIL...
  • Page 21 Distances in mm / 1D min code Distances in mm / 2D min code Device 35 mm HSLL 35 mm HSLL 1300 6 MIL 6 MIL 1750 8 MIL 1110 8 MIL 2170 10 MIL 1390 10 MIL DM37x 2820 13 MIL 1800 13 MIL 3250...

  • Page 22: Connecting The Reader

    Connecting the Reader CAUTION: The Ethernet cable shield must be grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector. A digital voltmeter should be used to validate the grounding.

  • Page 23: Installation

    Installation procedures and specifications are presented in detail in the DataMan 370 Series Reader Reference Manual, which is installed with the DataMan Setup Tool. From the Windows Start menu, select the following to access the manual: All Programs > Cognex > DataMan Software vx.x.x > Documentation. Note: Cables are sold separately.

  • Page 24: Connect The Ethernet Cable

    For more information on mounting, see the DataMan 370 ReaderSeries Reference Manual. Connect the Ethernet Cable CAUTION: The Ethernet cable shield must be grounded at the far end. Whatever this cable is plugged into (usually a switch or router) should have a grounded Ethernet connector.

  • Page 25: Connect The Breakout Cable

    Never connect voltages other than 24 VDC. Always observe the polarity shown. 3. Attach the Breakout cable's M12 connector to the DataMan 370 series reader's 24 VDC connector. 4. Restore power to the 24 VDC power supply and turn it on if necessary.
  • Page 26 3. Connect the cable to a 24V power supply. To configure a DataMan 370 series reader, the DataMan Setup Tool software must be installed on a networked PC. The DataMan Setup Tool is available from the DataMan support site: http://www.cognex.com/support/dataman.
  • Page 27 DataMan 370 Series Reader Specifications Specification DataMan 370 Reader Weight 165 g Power 24 VDC ±10%, 1.5 A maximum (HPIL* and HPIT**) Consumption 24 VDC , 250 mA maximum (non-HPIL)* 24 VDC, 1000 mA (HPIA)*** Supplied by LPS or NEC class 2 only.
  • Page 28 2.0 mA @ 24 VDC 4.2 mA Ethernet 10/100/1000 Speed Duplex Mode Full duplex or half duplex DataMan 370 Series Reader Imager Specifications Specification DataMan 374 Imager DataMan 375 Imager Image Sensor 1/1.8 inch CMOS 2/3 inch CMOS, global shutter...
  • Page 29 Max. 37 Hz at Full Resolution Lens Type See DataMan 370 Series Accessories on page 4 *Limitations to C-Mount lenses: The length of the thread may not exceed 5.4 mm. For a chosen lens, the distance from the C-mount shoulder to the bottom of the lens may not exceed 5.4 mm.
  • Page 30 Note: For the most current CE declaration and regulatory conformity information, see the Cognex support site: cognex.com/support. DataMan 370 Series readers have Regulatory Model R00051 and meet or exceed the requirements of all applicable standards organizations for safe operation. However, as with any electrical equipment, the best way to ensure safe operation is to operate them according to the agency guidelines that follow.

  • Page 31: For European Community Users

    UL 61010-1:2012 + R:2015-07, UL 61010-1:2012 + R:2015-07, EN 61010-1:2010. TÜV SÜD AM, IEC/EN 61010-1. CB report available upon request. For European Community Users Cognex complies with Directive 2012/19/EU OF THE EUROPEAN PARLIAMENT AND OF THE COUNCIL of 4 July 2012 on waste electrical and electronic equipment (WEEE).
  • Page 32 You may also contact your supplier for more information on the environmental performance of this product.
  • Page 33 中 国 大 陆 RoHS (Information for China RoHS Compliance) 根 据 中 国 大 陆 《 电 子 信 息 产 品 污 染 控 制 管 理 办 法 》 ( 也 称 为 中 国 大 陆 RoHS)， 以...
  • Page 34 Copyright © 2020 Cognex Corporation. All Rights Reserved.
