Delta Vivitek NovoTouch EK653i Quick Start Manual

Quick Start Guide
(For EK653i / EK753i / EK863i)
Vivitek America
46101 Fremont Blvd, Fremont, CA 94538
U.S.A.
T: +1-510-668-5100
F: +1-510-668-0680
Vivitek Asia
7F, No. 186, Ruey Kuang Road, Neihu, Taipei 11491,
Taiwan R.O.C.
T: +886-2-8797-2088
F: +886-2-6600-2358
Vivitek Europe
Zandsteen 15, 2132 MZ Hoofddorp
The Netherlands
T: +31-20-800-3960
F: +31-20-655-0999
www.vivitekcorp.com

Package Contents

Display Wi-Fi USB Module (with Antennas)
Power Cable Wall Mount

Display Overview (Front)

1 2
1 Magnetic Stylus Holders 3 IR Sensor (for Remote Control)
2 Power Button and Status Indicator LED 4 USB 2.0 Port x 2
Remote Control USB Cable
HDMI Cable VGA Cable

Display Overview (Rear)

8
7
1 3 4
1 Handles
2 Wall Mount Screw Holes
3 120-Pin OPS Slot (NovoConnect Module)
4 Power Switch
Audio Cable Stylus x 2
Batteries Quick Start Guide
1 2 1
6
5 Power Socket
6 Speakers
7 Wi-Fi Module Slot
8 80-Pin Standard Intel OPS Slot
3
4
5
