wheel into position (fig.14a).
- Move the column forward (fig.15).

DEMOUNTING

- Release the lock button, releasing
both the vertical and horizontals arm
(fig 15a), and position the mounting/
demounting device correctly against the
rim edge (fig.16).
IMPORTANT: pressing the button locks
both the vertical and horizontal arms
simultaneously.
This space between the rim and the verti-
54
cal slide will be maintained for as long as
the button is in the locking position.
The operator can tilt the tower freely (e.g..
when demounting wheels of the same size)
without repositioning the vertical slide.
14a
15
- Fit the bead lifter lever (Fig. 18) between
the mounting head and the tyre bead.
A
16
B
Operator's manual M 824
B
17
18
