Trane OxBox MAYKSKT001 Installation Manual

START CONTROL KIT INSTALLATION MANUAL
Before using your unit, please read this manual carefully and keep it for future reference.
Read the safety precautions carefully before installing the unit.
Stated below are important safety issues that must be obeyed.
Confirm there is no abnormal phenomena during test operation after complete, then leave the manual with the end user.
Meaning of marks:
Indicates a hazardous situation which, if not avoided, could result in death or serious injury.
WARNING
Indicates a hazardous situation which, if not avoided, could result in minor to moderate injury.
CAUTION
Please have a professional install this unit.
Installation by other persons may lead to improper installation, electric shock or fire.
Strictly follow this manual.
Improper installation may lead to electric shock or fire.
Reinstallation must be performed by professionals.
Improper installation may lead to electric shock or fire.
Do not disassemble the heat pump unless you are a professional servicing or repairing the unit.
Disassembly by a non-professional may cause abnormal operation or heating, which may result in fire.
Make sure all power to unit is turned off.
Before installing, modifying, or servicing system, main electrical disconnect switch must be in the OFF position and install a lockout
tag.There may be more than 1 disconnect switch. Always use a suitable warning label.
Beware of potential cut hazards.
Sheet metal parts may have sharp edges or burrs. Use care and wear appropriate protective clothing and gloves when handling
parts.
Follow all safety codes.
Wear safety glasses, protective clothing, and work gloves. Use wet cloth for brazing operations and have fire extinguisher available. Read
these instructions thoroughly and follow all warnings or cautions included in literature and attached to the unit. Consult local building codes
and current editions of the National Electrical Code ( NEC ) NFPA70. In Canada, refer to current editions of the Canadian electrical
code CSA 22.1.
MAYKSKT001
Thank you very much for purchasing our product.

SAFETY PRECAUTION

WARNING
CAUTION
1
88-MACC009-1A-EN
Version: MD18I-002AW
16123000A17435
