Trane BAYECON101A Installer's Manual

Model:
BAYECON101A
BAYECON102A
BAYRLAY004A
WARNING:
ALL phases of this installation must comply with NATIONAL, STATE AND LOCAL CODES
IMPORTANT — This Document is customer property and is to remain with this unit. Please return to service
information pack upon completion of work.
General
The economizer is a multi-damper design. It is installed in the
return air stream and is connected to the unit low voltage sup-
ply through wire leads. The economizer is fully accessible
through the Coil access panel.
Important: The Economizer installation requires that you first
install an air filter rack ordered separately. Use:
BAYFLTR101B for 2/4YC*, WC*, TC*, DC* *018-3036
BAYFLTR201B for 2/4YC*, WC*, TC*, DC* *042-3060.
When the economizer is installed in WC* models, relay
accessory kit BAYRLAY004A is required. Refer to the drawing
on page 9 to make your relay wiring connections in the Control
Box.
Identify Economizer Kit Contents
Refer to Figures 1 and 2 on page 2 to identify the kit
contents.
Inspect Contents
You must report damage and make claims to the transporta-
tion company immediately. Report missing parts to your sup-
plier immediately and replace with authorized parts only.
! WARNING
ELECTRIC SHOCK HAZARD
OPEN AND LOCK OUT ALL UNIT DISCONNECTS PRIOR TO
ACCESSORY INSTALLATION OR UNIT MAINTENANCE, TO
PREVENT INJURY OR DEATH FROM ELECTRICAL SHOCK OR
CONTACT WITH MOVING PARTS.
WARNING
!
SAFETY HAZARD
DO NOT REMOVE END COVERS FROM ECONOMIZER AC-
TUATOR; THE SPRING-RETURN ASSEMBLY MAY RELEASE
AND CAUSE PERSONAL INJURY.
Installer's Guide
Down Discharge Economizer and Rain Hood
Used with:
2/4TC*,WC*,YC*,DC* *018-036
2/4TC*,WC*,YC*, DC* *042-060
(Relay required in WC* Units)
HAZARDOUS VOLTAGE - DISCONNECT POWER BEFORE SERVICING
Install Economizer Kit
1. Remove Power
Disconnect and verify that power is off.
2. Remove Access Panels
Remove these four (4) access panels (see Figure 3, page 2):
• Control/Heat access panel
• Blower access panel
• Coil access panel
• Horizontal Return Air panel (discard or store)
3. Install Economizer Assembly
Note: You must first install the filter rack per the instruc-
tions provided and then install the economizer.
!
Use care when inserting the economizer in the return air com-
partment, to prevent damaging the foil faced insulation.
1. The economizer ships with the return air damper folded
up to allow the assembly to fit through the Coil opening
in the side of the unit, see Figures 1 and 2 on page 2.
Insert the economizer assembly into the unit through the
Coil access panel opening. See Figure 4 on page 3.
2. Swing the return air damper section down so that it rests
on the bottom of the unit. The economizer will sit
completely over the return air opening in the bottom of
the unit. See Figures 5 on page 4. Screw the economizer
assembly together with one assembly screw in the side of
the economizer. Tighten the linkage rod between the
return air dampers.
3. Insert 2 screws through the holes in the front face of the
unit and into the matching attachment holes in the econo
mizer assembly. See Figure 6 on page 4.
Insert a screw through the pre-punched hole in the side
4.
flange of the return air damper and into the mating hole
in the economizer assembly and tighten. See Figure 5 on
page 4.
18-HE39D8-10
CAUTION
