Installation Instructions
Precedent™ Packaged Rooftop
Units Low Leak Economizer
ReliaTel™ - Vertical Installation Only
Model Number:
Used With:
BAYECON705*
Precedent™ B/F cabinet with ReliaTel™ controls - WSC060EDR, T/YHC036E*R,
T/YHC037E*R, WSC036-048H*R, T/YZC036E*R, T/YSC036-060G*R, D/WHC036H*R
BAYECON704*
Precedent™ C/D/E cabinet with ReliaTel™ controls - T/YHC047-067E*R, T/YHC072-102F*R,
T/YHC120E*R, WSC060H*R, T/YSC(072-120)F/H*R, WSC072-120**R, T/YHC048-060F*R,
D/WHC048-120H*R, T/YZC048-120**R
Only qualified personnel should install and service the equipment. The installation, starting up, and servicing of
heating, ventilating, and air-conditioning equipment can be hazardous and requires specific knowledge and training.
Improperly installed, adjusted or altered equipment by an unqualified person could result in death or serious injury.
When working on the equipment, observe all precautions in the literature and on the tags, stickers, and labels that are
attached to the equipment.
January 2024
SAFETY WARNING
ACC-SVN177K-EN

Advertisement

loading
Need help?

Need help?

Do you have a question about the BAYECON705 Series and is the answer not in the manual?

Questions and answers

Summary of Contents for Trane BAYECON705 Series

  • Page 1 Installation Instructions Precedent™ Packaged Rooftop Units Low Leak Economizer ReliaTel™ - Vertical Installation Only Model Number: Used With: BAYECON705* Precedent™ B/F cabinet with ReliaTel™ controls - WSC060EDR, T/YHC036E*R, T/YHC037E*R, WSC036-048H*R, T/YZC036E*R, T/YSC036-060G*R, D/WHC036H*R BAYECON704* Precedent™ C/D/E cabinet with ReliaTel™ controls - T/YHC047-067E*R, T/YHC072-102F*R, T/YHC120E*R, WSC060H*R, T/YSC(072-120)F/H*R, WSC072-120**R, T/YHC048-060F*R, D/WHC048-120H*R, T/YZC048-120**R SAFETY WARNING...
  • Page 2: Warnings, Cautions, And Notices

    When working with or around hazardous chemicals, these compounds have the same potential impact to the ALWAYS refer to the appropriate SDS and OSHA/GHS environment. Trane advocates the responsible handling of all (Global Harmonized System of Classification and refrigerants. Labeling of Chemicals) guidelines for information on...
  • Page 3: Revision History

    Copyright This document and the information in it are the property of Trane, and may not be used or reproduced in whole or in part without written permission. Trane reserves the right to revise this publication at any time, and to make changes to its content without obligation to notify any person of such revision or change.
  • Page 4: General Information

    General Information Model Number Description All products are identified by a multiple-character model number that precisely identifies a particular type of unit. Its use will enable the owner/operator, installing contractors, and service engineers to define the operation, specific components, and other options for any specific unit. When ordering replacement parts or requesting service, be sure to refer to the specific model number and serial number.
  • Page 5: Mechanical Assembly

    Field Installed Assembly Figure 2. Gasket material position and Installation Corners of RTJ and Economizer This section covers installation of economizer units that were Top of Filler Panel not installed in the rooftop unit at the factory. Specifically, the following model numbers are included: BAYECON704* and Top of BAYECON705*.
  • Page 6: Smoke Detector

    Field Installed Assembly and Installation 15. If a powered exhaust is to be installed go to “Powered 9. Hook up electrical as described in Power Exhaust Kit - Exhaust,” p. Standard and Low Leak Economizers 6 to 10 Tons Installation Instructions (ACC-SVN57*-EN). 16.
  • Page 7 Field Installed Assembly and Installation Mixed Air Sensor Wiring 6. Shorten flexible tubing and connect from the copper tubing to the smoke detector unit. The black wires from the mixed air sensor plug into the Important: Verify holes in copper tube are facing down. ReliaTel™...
  • Page 8 Field Installed Assembly and Installation 7. Turn the MIN POS - DESIGN potentiometer on the RTEM Figure 11. RTEM board clockwise to open or counter-clockwise to close. This will set the minimum damper position at maximum fan speed. WHITE Range of damper for this setting is 0 to 50%. WHITE 8.
  • Page 9 Notes ACC-SVN177K-EN...
  • Page 10 Notes ACC-SVN177K-EN...
  • Page 11 Notes ACC-SVN177K-EN...
  • Page 12 For more information, please visit trane.com or americanstandardair.com. Trane and American Standard have a policy of continuous product and product data improvement and reserve the right to change design and specifications without notice. We are committed to using environmentally conscious print practices.
