System setup
11.1 Delay setting
Arm Delay
Gives the ability to use the arm key on the panel when leaving the guard area to delay the arming for
x seconds. You can set a delay of 0-255 seconds. In the delay arming status, the host beeps every
second till the delay is over and goes into arm status. The value zero means no delay on arming.
Alarm Delay
Gives the ability when entering the guard area to delay the alarm for x seconds. You can set a delay of
0-255 seconds. In the alarm delay status, the host beeps every second till the delay is over. The value
zero means no delay on alarm.
KR-K7 User manual
Picture 11-1
23

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the KR-K7 and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for KERUI KR-K7

Summary of Contents for KERUI KR-K7

  • Page 1 KR-K7 User manual System setup 11.1 Delay setting Picture 11-1 Arm Delay Gives the ability to use the arm key on the panel when leaving the guard area to delay the arming for x seconds. You can set a delay of 0-255 seconds. In the delay arming status, the host beeps every second till the delay is over and goes into arm status.

  • Page 2: Auto Arm/Disarm

    KR-K7 User manual 11.2 Auto Arm/Disarm On the page of Auto Arm/Disarm, you can program the first 8 zones to automatically Arm/Disarm. The setting supports “time”, “arm/disarm” and “day of week” choice. Picture 11-2 Delete auto arm/disarm To delete auto arm/disarm for a zone choose the zone that you want to delete. A dialog [edit/ delete] will pop up.

  • Page 3: Volume Adjustment

    KR-K7 User manual Volume adjustment 11.3 Picture 11-4 Voice volume: Ability to set the voice prompt volume (0-7) of the panel. 0 means voice prompt mute, 7 means the maximum volume. The default voice volume is 5. Alarm volume: Ability to set the alarm volume (0-7) when the panel alarms. 0 means alarm mute, 7 means the maximum alarm volume.

  • Page 4: Arm/Disarm Sms

    KR-K7 User manual 11.5 Arm/Disarm SMS Picture 11-6, in the disarming SMS notification page the user can select the desired SMS notification. Make sure to set the alarm numbers when enabling this function. Picture 11-6 11.6 Key Tone Picture 11-7...

  • Page 5: Screen Saver

    KR-K7 User manual 11.7 Screensaver Picture 11-8 On the Screensaver settings page there are six options, "30 seconds", "1 minute", "2 minutes" "5 minutes", "10 Minutes", "never". The factory default is 30 seconds, indicating that without any operation during 30 seconds, the host display will automatically turn off and be locked. Choosing “never”...
  • Page 6 KR-K7 User manual Administrator Password: Is 6 digits and used to enter the menu to program the host. This password is also used for remote setting, telephone, SMS settings and query using the app. The factory default administrator password is 123456.

  • Page 7: Power Alarm

    KR-K7 User manual 11.11 Power Alarm In the settings page of Power Alarm (Picture 11-12), there are 4 choices: Panel Power Off, Panel Power On, Panel Low Battery, and Sensor Low Battery. Picture 11-12 Panel Power OFF When “Panel Power Off” is chosen, four choices pop up:...

  • Page 8: Ready To Arm

    KR-K7 User manual 11.12 Ready to Arm This function checks if all door sensors are closed when arming. A door icon will be shown in the top menu of the host (red color when open, white when closed). When function switched ‘ON’ and a door is open, the system cannot arm and a voice alert sounds “XX zone on”.

  • Page 9: Restore Factory

    KR-K7 User manual 11.14 Contact ID CID No. is the account which is shown on the network center. Picture 11-15 11.15 Restore factory Restores the K7 panel to the factory defaults using three options: Delete Remotes： Delete all programmed remote controls.

  • Page 10: Phone Call

    KR-K7 User manual 11.16 Phone Call As Picture 11-17. In the Call Menu page user can dial any number, like a normal phone. Picture 11-17 11.17 Recording When alarming, the recording message will sound first when a telephone number is dialed.

  • Page 11: Alarm Log

    KR-K7 User manual 11.18 Alarm Log All alarms, arms and disarms are logged for audit use. Picture 11-19 Arm / Disarm Log As shown in Picture 11-20. In this page the last 99 arm/disarm recordings are shown, for each recording it shows the date, time and the device (Host, remote control, sms, wifi, gprs) used for arm/disarm/home.
  • Page 12 KR-K7 User manual Alarm Log As shown in Picture 11-21. This page shows the 15 most recent alarm events by the alarmed zone, date, time, etc. Picture 11-21 11.19 About me In the page ‘About Me’, the Version No, UI, IMei and MAC address are shown.
  • Page 13 KR-K7 User manual SMS Setting and Command Chart In addition to change settings through host menu or the K7 app, SMS using a phone or other device can be used to set panel settings using SMS codes. The syntax is as follows: [System Password][Command No][parameter1][parameter 2][parameter 3][parameter 4][parameter 5] All commands begins with system password, in below chart the system password is 123456.
  • Page 14 KR-K7 User manual Check Zone Type 01-99 Zone 1234561255 (Check No.55 zone type) Set the Remote no. 01~99 remote 1-Sound on 12345613200 Control sound control 0-Sound off (No 20 remote control without sound) Check the Remote No.01~99 remote 1234561333 Control control (Check Sound of No.
  • Page 15 KR-K7 User manual 27 Jan. 2016) Check System 12345620 Time and Date (Check System Time& Date) Set Volume 1-Voice 1234562125 2-Volume (Level) (Set Alarm Volume Level 3-Alarm as 5) 4-Volume Check Volume 1-VoiceVolume 123456211 2-AlarmVolume (Check Voice Volume) Set Alarm Siren...
  • Page 16 KR-K7 User manual characters) Check Zone SMS 1-99 Zone 1234562705 Message Content (Check Zone 5 Message Content) Arm/Disarm SMS 123/0 1234562812 1-Arming form (Set Arm, Disarm Inform 2-Disarm inform STAY not Inform) 3-Stay inform 123456280 0-No inform (No Inform to Arm/Disarm)

  • Page 17: Add New User

    KR-K7 User manual GPRS Management A network alarm client management software is released by our company, which is low cost but powerful and can be used by alarm centers, security service companies, police, military, financial industry, museums and other environments.

  • Page 18: Phone Register

    SMS messages back to your phone. Besides SMS also the phone connection can be used to contact the KR-K7 panel in order to ‘listen’ or see what is happening. So make sure you have enough SMS credits on your sim for both phone and panel.
  • Page 19 KR-K7 User manual Host number: Enter the telephone number of your Sim card installed in the KR-K7 panel. User name: Set a user name Password (confirm): Enter the password of your admin account on the KR-K7 panel Press the checkmark in the top right corner 14.2 Email Register...
  • Page 20 KR-K7 User manual 14.3 Binding equipment Under App page, If the device shows under {on-line device page}, after clicked on the {unbound device page}, it means successfully. Mobile phone can detect the other device automatically under the LAN. Online device: The device enters the network successes, and the network well, the cell phone bind with network.

  • Page 21: Device Property

    It included" Device Name", "Device Password"," Voice" {Delete} Device name: Here you can see and edit the device name of the KR-K7 panel. Device Password: Here you can change the password. The original password is 123456.
  • Page 22 KR-K7 User manual Equipment Management: Click [Device Management] into the device management page or the drop- down menu, you can choose to use different alarm host; Account Management: Click to enter the [User Management] page, change the user password; click on the page [cancel] key, you can log off, when APP open again, need to re-enter your user name and password.
  • Page 23 K7 panel SIM. The KR-K7 Panel will sound a “di” and respond with a reply SMS message: <Position No>:<Phone number>,<Alarm setting> Pressing the lens glass will send an request to the KR-K7 to reply with the current setting. The Panel will sound a “di” and respond with a reply SMS message: <Position No>:<Phone number>,<Alarm setting>...
  • Page 24 KR-K7 User manual When sliding from left t right a menu is opened that shows: User name: The name of the logged in user Host: The host name Password: The Password In the lower part of the menu shows: Change Host: Ability to change to another host...

  • Page 25: Remote Control Via Phone

    KR-K7 User manual Measures after Receiving Alarm When there is an alarm the host will dial the preset phone number and text an SMS message automatically and siren the alarm according to the setting. If the owner’s phone is busy or couldn’t be connected the host will dial the next alarm phone number and it will dial all the preset phone numbers 3 times repeatedly.

  • Page 26: System Technical Parameters

    KR-K7 User manual System Parameters 17.1 System Factory Default Zone Type Normal Stay Zone Intelligent Intelligent Doorbell Welcome Emergency Zone Zone Stay Zone Zone Zone Zone 01-59 60-79 80-89 90 Zone 91 Zone 92 Zone 93-99 Zone Zone Zone Zone 17.2 System Factory Default Value...

  • Page 27: Replacing The Battery

    KR-K7 User manual Installation and Usage of Sensors 18.1 Installation and Use of Door Sensor Door sensor makes use of magnetic induction to detect close and open state, and consists of a transmitter (A) and a magnet (B). It can be installed on doors, windows or any object that can be closed and opened.
  • Page 28 KR-K7 User manual 18.3 Installation and Use of PIR Motion Sensor Open the power switch before using. Installation height is about 2.2 meters above ground and it should be installed in the corner of the room to get the best detection range and should form a certain...
  • Page 29 KR-K7 User manual Other sensors that can be used Smoke sensor Wired siren PIR room sensor PIR curtain sensor Wireless siren Outdoor siren Emergency key Sensor repeater Gas detector Smart socket Water detector Emergency button Camera Shock sensor Doorbel...

  • Page 30: Troubleshooting

    KR-K7 User manual Trouble Shooting Reasons Methods Troubleshooting 1. No dial for alarm 1. No arming 1. Perform arming operation 2. Alarm phone unset 2. re-set according to the specification 3. Parts improperly installed, 3. coordinating the location of parts distance too far 4.
  • Page 31 KR-K7 User manual Sensor Zone list Zone Sensors Siren Attribute Event code On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off...
  • Page 32 KR-K7 User manual On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off...
  • Page 33 KR-K7 User manual Zone Sensors Siren Attribute Event code On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off On/Off...
