DVI-E input
Note
Power supply
USB-Extended input
Protective Earthing
CP79xx
Connector description
DVI-Extended (Digital Visual Interface-Extended)
The DVI-E connection (X101) is used for transferring the video signal from
the Industrial PC to the Control Panel.
The graphics signal is transferred directly via a DVI cable over a distance
of 50 m max. Such a cable length leads to strong distortion of the graphics
signal on arrival at the Control Panel. The CP79xx "Economy" Control
Panel features a signal processor that restores the DVI signal. The PC
requires a conventional DVI output.
The transmission rate of the DDC file has to be limited
At large distance between PC and Control Panel, the transmission rate of
the DDC file has to be limited.
See also chapter
Setting the transmission
Power supply
The power supply for the Control Panel is established via the 4-pole M12
socket (X102).
USB-Extended interface
The Control Panel is connected with the CU8800 USB to USB extended
converter box via the USB-Extended input (X103).
In order to realize a distance of 50 m without hubs, with USB extended the
USB signal is converted so that it can be transferred via 50 m CAT5 cables
commonly used for Ethernet wiring. In the Control Panel the signal is
converted back to USB.
Protective Earthing
The low resistance protective earthing connection is
established via the ground bolt, which is located near the
power supply connector.
Control Panel Connecting Kits
Cable Set
C9900-K434
Connecting kit 3 m for CP79xx including: 3 m DVI cable, 3 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K435
Connecting kit 5 m for CP79xx including: 5 m DVI cable, 5 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K436
Connecting kit 10 m for CP79xx including: 10 m DVI cable, 10 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K437
Connecting kit 20 m for CP79xx including: 20 m DVI cable, 20 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K438
Connecting kit 30 m for CP79xx including: 30 m DVI cable, 30 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K439
Connecting kit 40 m for CP79xx including: 40 m DVI cable, 40 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
C9900-K440
Connecting kit 50 m for CP79xx including: 50 m DVI cable, 50 m CAT5
cable for USB-E, USB to USB-E converter CU8800 for mounting rail
installation close to the PC and 1 m USB cable to connect the USB to
USB-E converter to the PC
Product Description
rate.
