______ Index Package Contents Mount Outside Antenna STEP 1: Route & Connect Booster STEP 2: Route Cable To Front Of Vehicle STEP 3: Connect System To Power STEP 4: Insert Phone Into Cradle STEP 5: Troubleshooting Safety Guidelines Specifications Warranty...
Page 3
________ Package Contents Outside Signal Power Sleek Antenna Booster Supply Cradle Magnetic Adhesive Magnetic Vent Mount Dash Mount (for cradle) (for cradle) DRIVE SLEEK CELL PHONE SIGNAL BOOSTER...
Page 4
NOTE: For aluminum roofs, an adhesive disk is included to mount the outside antenna (do not use if outside antenna will magnetize to the top of your vehicle). WORKS WITH ALL VEHICLES CELL PHONE SIGNAL BOOSTER DRIVE SLEEK...
Page 5
Car/Sedan: Cable routed into rear side door. NOTE: When going through car wash, remember to remove your antenna. SUV/Van/Hatchback: Cable routed into top of hatchback door. Truck: Cable routed into side door. DRIVE SLEEK CELL PHONE SIGNAL BOOSTER...
Page 6
(damaging the booster). NOTE: The “hook” side of the Velcro ® (already on the booster) can be used to attach to the carpet of many vehicles. Velcro ® bottom side of booster CELL PHONE SIGNAL BOOSTER DRIVE SLEEK...
We recommend routing the 15ft. fixed cable from the booster, under mats and between seats up to the front of the vehicle where the cradle will be located. to front of vehicle Connect booster cable to cradle cable. snap-in connectors cradle DRIVE SLEEK CELL PHONE SIGNAL BOOSTER...
If your vehicle always has power going to this port, you may want to unplug this when you’re not driving so the booster does not drain your battery. Only 12V ports are supported. cable from power supply CELL PHONE SIGNAL BOOSTER DRIVE SLEEK...
NOTE: A Magnetic Vent Mount & Adhesive Magnetic Dash Mount are provided which provides a versatile, safe and functional smartphone solution. IMPORTANT: The FCC requires to never use the cell phone in the cradle next to your ear. DRIVE SLEEK CELL PHONE SIGNAL BOOSTER...
Check/secure power connections to the CLA, booster, and cradle. If light shuts off, remove from vehicle port and plug back in to reset the system. For any questions or assistance contact our weBoost Customer Support Team (1-866-294-1660). Dropped Calls If you are regularly experiencing dropped calls in the same areas, turn off VoLTE/HD Voice in your phone’s settings.
______ Safety Guidelines Use only the power supply provided in this package. Use of a non-weBoost product may damage your equipment. All inside antennas must have at least 1.5’ separation distance from all active users. RF Safety Warning: Any antenna used with this device must be located at least 8 inches from all persons.
(2). This device must accept any interference, including interference that may cause undesired operation of the device. Changes or modifications not expressly approved by weBoost could void the authority to operate this equipment. CELL PHONE SIGNAL BOOSTER DRIVE SLEEK...
2 YEAR WARRANTY weBoost Signal Boosters are warranted for two (2) years against defects in workmanship and/or materials. Warranty cases may be resolved by returning the product directly to the reseller with a dated proof of purchase. Signal Boosters may also be returned directly to the manufacturer at the consumer’s expense, with a dated proof of purchase and a Returned Material...
Page 14
Notes weboost.ca 866.294.1660 NEED HELP? CELL PHONE SIGNAL BOOSTER DRIVE SLEEK...
Page 15
Notes weboost.ca 866.294.1660 NEED HELP? DRIVE SLEEK CELL PHONE SIGNAL BOOSTER...
Page 17
UNE MARQUE WILSON ELECTRONICS Kit d’Amplification du Signal pour Véhicule DRIVE SLEEK Guide de l’Utilisateur www.weboost.ca 866.294.1660 BESOIN D’AIDE?
Page 18
______ Table des Matières Contenu de l’Emballage Montage de l’Antenne Extérieure ÉTAPE 1: Placement et Connexion de l’Amplificateur ÉTAPE 2: Acheminer le Câble vers l’Avant du Véhicule ÉTAPE 3: Connecter le Système à l’Alimentation ÉTAPE 4: Insérer le Téléphone dans le Berceau ÉTAPE 5: Résolution des Problèmes Consignes de Sécurité...
________ Contenu de l’Emballage Antenne Amplificateur Bloc Berceau Extérieure de Signal d’Alimentation Sleek Support de montage Support adhésif magnétique pour aération magnétique pour tableau (pour berceau) (pour berceau) DRIVE SLEEK AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE...
Page 20
REMARQUE: Une bande adhésive est fournie pour les toits en aluminium afin de fixer l’an-tenne extérieure (ne l’utilisez pas si l’antenne extérieure est montée avec un support magnétique sur le toit de votre véhicule). FONCTIONNE AVEC TOUS LES VÉHICULES AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE DRIVE SLEEK...
Page 21
REMARQUE: N’oubliez pas de retirer votre antenne lorsque vous allez dans un lave-auto. VUS/Van/Hayon: Câble acheminé au haut de la porte hayon. Camion: Câble acheminé dans la porte latérale. DRIVE SLEEK AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE...
Page 22
être accrochés ou abîmés (ce qui endommage l’amplificateur). REMARQUE: Le côté en crochet du Velcro® (déjà placé sur l’amplificateur) peut servir à monter le système sur le tapis de beaucoup de véhicules. Velcro ® Sous l’amplificateur AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE DRIVE SLEEK...
12V CLA. Si ce port de votre véhicule est toujours alimenté, il est ANTENNA recommandé de le débrancher lorsque vous ne conduisez pas pour éviter que l’amplificateur vide votre batterie. *Seuls les ports 12V sont pris en charge. de câble d’alimentation AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE DRIVE SLEEK...
Page 25
IMPORTANT: La FCC exige de ne jamais utiliser un téléphone cellulaire dans le berceau près de votre oreille. DRIVE SLEEK AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE...
Si le voyant s’éteint, débranchez-le du port du véhicule, rebranchez- le pour réinitialiser le système. Si vous avez des questions ou besoin d’aide, contactez notre service de Soutient technique weBoost au 1-866-294-1660. Pertes d’Appels Si vos appels sont régulièrement interrompus aux mêmes endroits, désactivez l’option VoLTE/HD Voice sur votre téléphone.
Utilisez uniquement le bloc d’alimentation fourni dans cet emballage. Si vous utilisez un produit qui n’est pas un produit weBoost, vous pourriez endommager votre matériel. Toutes les antennes intérieures doivent être installées à une distance d’au moins 4 cm (1,5 pouce) de tout autre utilisateur actif.
: 1) ce dispositif ne doit pas causer d’interférences; 2) ce dispositif doit accepter toutes les interférences, y compris celles pouvant entraîner un fonctionnement indésirable de l’appareil. Les changements ou modifications non expressément approuvés par weBoost pourraient annuler l’autorisation d’utiliser cet équipement. AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE...
Page 29
GARANTIE DE 2 ANS Les amplificateurs de signal de weBoost sont garantis contre tout défaut de fabrication ou de matériaux pendant deux (2) ans. Les réclamations en vertu de la garantie peuvent être réglées en retournant le produit directement au revendeur avec une preuve d’achat datée.
Page 30
Remarques www.weboost.ca 866.294.1660 BESOIN D’AIDE? AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE DRIVE SLEEK...
Page 31
Remarques www.weboost.ca 866.294.1660 BESOIN D’AIDE? DRIVE SLEEK AMPLIFICATEUR DE SIGNAL POUR TÉLÉPHONE CELLULLAIRE...
