3 Connections

Familiarize yourself with the ION-E100-HD front and rear panels before connecting any
equipment to the unit. The ION-E100-HD offers a single analog video input and associated I/Os
and audio connections.

3.1 Front Panel


VIDEO IN
HDMI connector interface for video input source (720p).

MICRO SD (optional)
Micro SD connector available for edge recording capability. Please insert a formatted
(FAT) micro SD card to enable associated functionality.
Note: A micro SD card is not provided with the device.
