- Page 1 CEILING MOUNT ADDENDUM 2/3/2020 Ceiling Mount 4000 Ceiling Mount 8000 Ceiling Mount Twin...
- Page 2 WhisperKOOL. Every effort has been made to ensure that the information in this manual is accurate. WhisperKOOL is not responsible for printing or clerical errors.
-
Page 3: Table Of Contents
TABLE OF CONTENTS Filter ............. 3 Line Set, Drain Tube, and Electrical Connections . - Page 4 WARNING The evaporator unit (fan coil unit) must be insulated using the insulation blanket provided in accordance with this manual. Refer to the insulation blanket installation instructions. Failure to follow the instructions provided will result in a poor vapor barrier, water damage, rust, and system corrosion which will void the warranty on your unit.
-
Page 5: Filter
Ceiling Mount - Addendum FILTER Washable filter is installed from the factory on the return side of the grille, secured via Velcro strips. www.whisperkool.com | Page 3... -
Page 6: Line Set, Drain Tube, And Electrical Connections
LINE SET, DRAIN TUBE, and ELECTRICAL CONNECTIONS • Line set, drain tube and electrical connections have been relocated to be accessible from the bottom (cellar side / grille side) located on return side of unit. • Can be accessed by removing the grille. •... -
Page 7: Speed Switch
Ceiling Mount - Addendum 2 SPEED SWITCH • The WhisperKool Ceiling mount now comes equipped with a 2-speed fan switch. • Located on the electrical panel. Access by removing grille and internal access panel. • Speed is sent from factory set to High. Flip the switch to adjust down to Medium speed. -
Page 8: Insulation Blanket Installation
• Ceiling Mount evaporator dimensions (including insulation blanket): 36.25”L x 15”W x 13”H. • Whisperkool recommends constructing the frame using dimensions which include the insulation blanket to ensure proper fitment. *Tools required: spray adhesive, utility knife, cork tape, foil tape Mini Ceiling Mount blanket dimensions 68”... - Page 9 10. Once insulation is installed, apply foil tape to all seams, covering them completely. 11. Inspect insulation for damage/defects. If damaged, repair with foil tape. 12. Apply cork tape or equivalent to areas where the line set, wiring, and drain line enter the unit. www.whisperkool.com | Page 7...
-
Page 10: Wiring Diagrams
WIRING DIAGRAMS ELIWELL RTN400 KDT PLUS DISPLAY Pb3 CPB KEYB NEUTRAL LINE OUT 2 OUT 3 OUT 4 NEUTRAL LINE OUT 1 WHITE BLACK BLACK BLACK BLACK BLACK RESERVOIR CONDENSATE PUMP VERSION 3 BLUE BLACK 115V LINE WHITE 115V NEUTRAL GROUND GREEN GREEN... - Page 11 WIRES COMING FROM BLACK WHITE WHITE MASTER UNIT RESERVOIR LEGEND Field Installed CONDENSATE PUMP Factory Installed BLUE BLACK 115V LINE WHITE 115V NEUTRAL GREEN GREEN GROUND GREEN GREEN BLUE 146mm BLACK WHITE Blower BROWN GREY Capacitor www.whisperkool.com | Page 9...
- Page 12 WhisperKOOL 1738 E. Alpine Ave Stockton, CA 95205 1-800-343-9463 www.whisperkool.com...
