Summary of Contents for Atlantic Technology System 4200
- Page 1 System 4200 THX Select High Performance C.O.R.E. Technology Loudspeaker Components...
-
Page 2: Table Of Contents
Serial Number Date of Purchase The contents of this manual are Copyright © 2003 by Atlantic Technology International, Corp., and may not be duplicated or reproduced by any means, whether physical, electronic or otherwise without prior written consent from Atlantic Technology International, Corp. -
Page 3: What's Thx
The room sizes simply provide a frame of reference, as they indi- cate that these systems must deliver a minimum level of performance in this specified room size. Your System 4200 is THX Select certified. For more information, visit the THX website at www.thx.com. -
Page 4: Models 4200 Sr Surround Speakers
Dipole and Bipole operation. These settings are explained on page 8, “Dipole/Bipole Operation of the SR Speakers. ” NOTE: Although the speakers in the Atlantic Technology System 4200 are acoustically and cosmetically matched to each other for ideal... - Page 5 Instruction Manual Speaker Placement Left Surround Speakers should be placed directly to the sides of the seating area and approximately 3 feet (1 meter) above the listener’s ear level. Left Surround Left Surround Back Front Speaker Array should be placed as close to ear level as possible.
-
Page 6: Stereo Systems
If the sound seems “hollow”, unusually spread out, or seem to have weak bass, recheck your connections for proper polarity and correct any out of phase connections, if necessary. System 4200 High Performance Loudspeakers... -
Page 7: System Wiring
Instruction Manual System Wiring Be sure to connect red (+) on the speaker to red (+) on the amplifier and black (–) on the speaker to black (–) on the amplifier. LEFT SURROUND SURROUND LEFT CENTER RIGHT System Wiring RIGHT... -
Page 8: System Setup
Bass Management menu, which typically requires you to select between “Small” or “Large” speakers during system set-up. Since these systems have been designed to work with a dedicated subwoofer, please set all the speakers in System 4200 to Small. HF ENERGY REVERBERANT... -
Page 9: Setting Levels
These systems will play very loudly when provided with enough undistorted power to do so. If necessary, consult your dealer or Atlantic Technology for additional information. Mounting... -
Page 10: Care Of Your Speakers
16lbs; 7.26kg w/base 11lbs; 4.99kg *Height includes tilt base. Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifications or appearance at any time without notice. THX, and THX Select are trademarks of THX Inc. Dolby Digital, 5.1, Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation. - Page 11 Notes Instruction Manual...
- Page 12 343 Vanderbilt Avenue Norwood, MA 02062 (781) 762-6300 www.atlantictechnology.com 015-1411...
