FS-4000 and FS-5000
Front Stage Loudspeakers
FS-4000
FS-5000

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the FS-4000 and is the answer not in the manual?

Questions and answers

Related Manuals for Atlantic Technology FS-4000

Summary of Contents for Atlantic Technology FS-4000

  • Page 1 FS-4000 and FS-5000 Front Stage Loudspeakers FS-4000 FS-5000...

  • Page 2: Table Of Contents

    Serial Number Date of Purchase The contents of this manual are Copyright © 2006 by Atlantic Technology International, Corp., and may not be duplicated or reproduced by any means, whether physical, electronic or otherwise without prior written consent from Atlantic Technology International, Corp.

  • Page 3: Description

    Acoustic Controls System FS-4000 and FS-5000 include unique acoustic controls to help maximize their performance in your room. These controls are explained in greater detail on page 6.

  • Page 4: Placement

    Placement Placement Speaker Placement and Home Theater Remember that the primary goal of a good home theater is not to make you believe that you are in a movie theater. It’s to make you believe you’re in the movie. For a home theater system, place the speaker either above or below your flat screen display, centered horizontally.

  • Page 5: Assembling The Speakers

    Instruction Manual Assembling the Speaker Figure 5 Stud Bracket installation Screw stud bracket through drywall into stud through aligning holes on bracket as shown. Make sure the closed side of the brackets are facing the ends of the speaker Double Keyhole for flush mounting Figure 9 Rocker installation...

  • Page 6: System Setup

    System Setup System Setup Using the Rear Panel Controls This control changes the tilt or rolloff HF Energy slope of the tweeter in order to compensate for varying room acoustics. Use the Average position for rooms with a reasonably balanced combina- tion of hard reflective surfaces (sliding glass doors and bare walls) and soft absorptive surfaces (thick carpeted floors and overstuffed furniture).

  • Page 7: Speaker Placement - Optional Surround And Subwoofer

    System Setup Instruction Manual Speaker Placement — Optional Surround and Subwoofer...

  • Page 8: Using Surround Speakers

    These systems will play very loudly when provided with enough undistorted power to do so. If necessary, consult your dealer or Atlantic Technology for additional information. Connecting Your System...

  • Page 9: System Wiring

    Instruction Manual System Wiring Be sure to connect red (+) on the speaker to red (+) on the amplifier and black (–) on the speaker to black (–) on the amplifier. Rear of Surround Sound Processor LEFT SURROUND SURROUND LEFT CENTER RIGHT Optional Surround Speakers...

  • Page 10: Care Of Your Speakers

    Care of Your Speakers Care of Your Speakers Clean your cabinets using a soft, lint-free cloth. If you wish, you can slightly moisten the cloth with plain water. Do not use any other cleaning agents or chemicals. Be careful not to get any water on the driver cones or tweeter domes.

  • Page 11: Specifications

    ⁄ " (28mm) height for base. Specifications are those in effect at the time of printing. Atlantic Technology reserves the right to change specifica- tions or appearance at any time without notice. Dolby Digital, 5.1, Dolby Stereo and Dolby Pro Logic are trademarks of Dolby Laboratories Licensing Corporation.
