Midea B5D Instruction Manual page 3

Product Introduction
Parts display
Switch button
Power indicator
light
Dust cup assembly
Charging
base
Plug
Flap the vibration block
Suction port
UV sensor light
UV lamp
Function Operation
Battery status
Notes
Please place it following the arrows on the illustration to ensure
proper charging.
State Indicator light for battery status
In the charging Flash once every second from left to right
Charging completed The indicator light stays on for 10 minutes and then goes off
Power consumption Decrease from right to left
Insufficient remaining power The leftmost light flashes, which prompts charging
Function Operation
Sweeping
According to the area of the cleaned object, the user can adjust the
handle to two directions such as vertical and horizontal directions. Press
the switch button to push back and forth to achieve cleaning.
The handle can
be rotated 90°
Push back
Sofa, pillow
and forth
etc.
Cleaning and Maintenance
Dust cup cleaning
1. When the dust reaches the max scale line on the cup, the dust cup
is taken out along the direction of the arrow.
2. Above the trash can, take out the filter components and clean the
dust.
