DICHROIC ASSEMBLY
Parts needed for this step:
STOCK #
85713
85710
N/A
85624
85632
85737
86018
PROPRIETARY - Property of Edmund Optics, Inc. | 2012 Copyright© Edmund Optics, Inc.
Description
25.4mm Dia. Adapter for 85710
Square Tip/Tile Optic Mount
25mm Dia. Dichroic of choice (see details under filter)
Cage Sphere with (5) 30mm Port and (1) 43mm Port
25mm Standard Cage Plate with M6 for Post Mounting
30mm Square Interface Plate
Filter Holder Plate
QUANTITY
1
1
1
1
1
1
2
7
