2.7
Install a CD-ROM drive
A CD-ROM drive is an optional item in this barebone system. Refer to the
instructions in this section if you acquired a model without a CD-ROM.
Follow these steps to install a
CD-ROM drive.
1.
Place the chassis upright.
2.
Insert the CD-ROM drive into
the upper 5.25-inch drive bay.
3.
Carefully push the CD-ROM
drive into the bay until its
screw holes align with the
holes (marked 1) on the bay
as shown.
4.
Secure the CD-ROM with two
screws on each side of the
bay.
26
5.25-inch drive bay
CD-ROM screws
Chapter 2: Basic Installation
