1.3
Internal Features
The figure below shows the internal view of the system when you remove
the cover and flip out the drive frame. You will see here the standard
components that come already installed in the system and the places
where you can install the other required components to get the system
running.
Game/MIDI/COM1
Extension Module
Modem Card
(optional)
14
Two 5.25"
Drive Bays
USB/audio
Motherboard
Board
Chapter 1: System Introduction
3.5" HDD
Drive Bay
3.5" Floppy Drive
Power Supply
