CONGRATULATIONS!
Thank you for purchasing MRC's advanced AC dual power train control.
MRC's Pure Power Dual has all the power needed to operate your AC
powered trains. The true state of art and pure smooth Sine Wave Technology
will enhance the performance of your layout for years to come.

CONTROLS

THROTTLE HANDLES

Install the two throttle handles by pressing them onto the sides of the
unit. Should the handles become loose, apply some self-adhesive tape
to the shaft and then reinstall the throttle handles.

MASTER ON/OFF SWITCH

The master on-off switch disconnects the input power from your MRC
Pure Power Dual and shuts the unit down completely. The pilot light will
glow when the unit is turned on.

DIRECTION BUTTONS

The direction buttons disable the voltage applied to the track and thereby
reverses the direction of your locomotive. This button should only be
operated when the locomotive is not moving. Pressing the direction
button once will cause the loco to idle. Pressed again, the locomotive will
travel in the opposite direction. However, the locomotive will reverse
direction after the speed control is turned to 0 and the speed control
advanced twice. This button will not control locomotives that do not have
an E-unit or if the E-unit is deactivated. If you are going to operate the
locomotive in one direction, such as on a layout with automatic station
stops or insulated blocks, the E-unit must be turned off and the direction
button will be inoperative.

THROTTLE CONTROL

The throttle is used to set the speed of the locomotive you are
controlling. Remember, if your locomotive is equipped with an E-unit, the
locomotive will change state after the speed control is turned to 0 and
the speed control advanced twice again.

HORN/WHISTLE BUTTON

This button is a spring return button. To activate a horn or whistle on your
locomotive, push the button. The sound will stay on as long as the button
is held down.

BELL BUTTON

This button is a spring return button. To activate the bell on your
locomotive, (if equipped), press and hold the button until the bell sounds.
The bell will remain activated until you press and hold the button to
deactivate the bell.
