IPF-2002L Quick Installation Guide
Package Contents：
One IPF-2002L VoIP phone
One power adaptor
One RJ-45 Ethernet cable
Quick Installation Guide
Installation CD
A
Dio
RT
l
l
i
g
e
n
c
e
C
o
m
m
l
l
i
g
e
n
c
e
C
o
m
m
IPF-2002L
V1.0
Version
IPF-2002L VoIP IP-Phone
u
n
i
c
a
t
i
o
n
u
n
i
c
a
t
i
o
n

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the IPF-2002L and is the answer not in the manual?

Questions and answers

Related Manuals for ArtDio IPF-2002L

Summary of Contents for ArtDio IPF-2002L

  • Page 1 IPF-2002L IPF-2002L Quick Installation Guide V1.0 IPF-2002L VoIP IP-Phone Package Contents： One IPF-2002L VoIP phone One power adaptor One RJ-45 Ethernet cable Quick Installation Guide Installation CD Version...

  • Page 2: Safety Instructions

    QIG of IPF-2002L ARTDio Company Inc. Safety Instructions Safety Instructions Do not attempt to service the product yourself. Any servicing of this product should be referred to qualified service personal. To avoid electric shock, do not put your finger, pin, wire, or any other metal objects into vents and gaps.
  • Page 3 QIG of IPF-2002L Step 1. Hardware Installation： 1.1：IPF-2002L Function Keys...

  • Page 4: Step 2. Hardware Installation

    (1) For the Cable ISP subscriber： Plug one end of the RJ-45 cable to one of the LAN port on the IPF-2002L, and plug another end to one of the LAN port of your router. Once “Ready for call” is shown on the screen, the hardware installation is completed.
  • Page 5 QIG of IPF-2002L (2) Connection without a router： Plug one end of the RJ-45 cable to one of the LAN port on IPF-2002L, and plug another end to one of the LAN port of your HUB. Once “Ready for call” is shown on the screen, the hardware installation is completed.

  • Page 6: Step 3 . Network Settings

    Step 3 Network Settings： 3.1 DHCP Setting： Connect the RJ-45 cable to the LAN port on the IPF-2002L, and then plug in the power. Press 1234# (Hold the # key) press ENTER LCD shows【network settings】. Press ENTER LCD shows【iptype】 Press 1 and then press ENTER (1 sets your networking settings to the DHCP mode).
  • Page 7 3.2 Static IP Setting： Connect the RJ-45 Ethernet Cable to the LAN port on the IPF-2002L, and then plug in the power. Press 1234# (Hold the “#” key) press ENTER LCD shows【network settings】. Press ENTER LCD shows【iptype】 Press 0 and then press ENTER. (0 sets your networking settings to the Static IP mode) LCD shows 【...
  • Page 8 3.4 NAT Environment configuration： If the IPF-2002L is under the NAT environment (Press the IP button on the IPF-2002L, if the LCD shows the IP address as 192.168.x.x or 10.x.x.x), please contact your VoIP service provider for the information.

  • Page 9: Step 5. Registration Message

    . You can acquire IPF-2002L’s IP address by pressing the IP button on the phone. The default password for IPF-2002L is 12345678. By input the password and then click the “Login” button, you can connect to your IPF-2002L web configuration page.

  • Page 10: Step 7. Some Troubleshooting

    Please check the Internet connection of the RJ-45 is ok. Please check if the IPF-2002L is able to acquire an IP address. If not, please check the Network Setting and see if the configuration is correct. Please verify that the account is valid. Please contact you VoIP service provider for the account information.
