Connector Outputs – ECY-STAT-R
Connector Label Output Type
C Com
Rc 24VAC
G DUO1
Y1 DO2
Y2 DO3
DO8/C8 DO8
Rh 24VAC
W1/OB DO4
W2/Y3 DO5
DUO6 DUO6
DUO7 DUO7
Table 3: Connector Outputs – ECY-STAT-R
Connector Outputs – ECY-STAT-F
Connector Label Output Type
C Com
Rc 24VAC
G DUO1
Y1 DO2
Y2 DO3
DO8/C8 DO8
Rh 24VAC
W1/OB DO4
W2/Y3 DO5
DUO6 DUO6
DUO7 DUO7
Table 4: Connector Outputs – ECY-STAT-F
Connector Outputs – ECY-STAT-Z
Connector Label Output Type
C Com
Rc 24VAC
G DUO1
Y1 DO2
Y2 DO3
DO8/C8 DO8
Rh 24VAC
W1/OB DO4
W2/Y3 DO5
DUO6 DUO6
DUO7 DUO7
Table 5: Connector Outputs – ECY-STAT-Z
6 / 17
Description
Common
24v Cooling (default jumper installed with Rc)
Fan ON-OFF - 0-10V
Cool 1 ON/OFF
Cool 2 ON/OFF
AUX Heat (ON-OFF)
24v Heating (default jumper installed with Rh)
Heat 1 ON/OFF - OB Valve
Heat 2 ON/OFF - Cool 3 ON/OFF
Econo - ON/OFF - 0-10V
Bypass damper / Humid / deHum - ON/OFF - 0-10V
Description
Common
24v Cooling (default jumper installed with Rc)
Fan ON/OFF - FAN (Low) - ECM (0-10V)
FAN (Med)
FAN (High)
AUX Heat (ON-OFF)
24v Heating (default jumper installed with Rh)
Cool/Heat (ON/OFF) - Cool/Heat (float open)
Cool/Heat (ON/OFF) - Cool/Heat (float closed)
Cool (0-10V) - Heat (0-10V) - OA Damper - Cool/Heat (float open)
Cool/Heat (float closed)
Description
Common
24v Cooling (default jumper installed with Rc)
NC
NC
NC
Aux Heat (ON/OFF)
24v Heating (default jumper installed with Rh)
Heat (ON/OFF) - Heat (float open) - Damper (float open)
Heat (ON/OFF) - Heat (float closed) - Damper (float closed)
Heat/Cool (0-10V) - OA Damper - Heat (float open) - Damper (float open)
Heat/Cool (0-10V) - OA Damper - Heat (float closed) - Damper (float closed)
