Bosch Rexroth AG
Technical data

7.1.2 Input system (multi-touch front)

The maximum permissible number and type of defects on the front or the glass,
such as trapped dust, scratches, etc. is defined in the FT
devices meet the quality guideline.

7.2 E-STOP button

Vendor
Switch type
Contacts
B10 value
Service life at 10 mA and 24 V DC
Tab. 7-2: E-STOP button data
1)
Quality standard (version December 2013) of the Fachgemeinschaft Eingabesysteme (German
association for input systems)
10/53
VEP 15.6 Multi Touch, VEP 21.6 Multi
1)
RAFI
RAFIX 22 FS + , ordering no. 130.273.301/2200
Reset by rotation
Protection type at front IP65 (DIN EN 60529)
2 × N/C contacts
1.300.000
1.000.000
DOK-SUPPL*-VEPXX.6MTHU-IT02-EN-P
Touch
. The VEP multi-touch
