Monitor Friction Loss - Task Force Tips PROTECTOR Instructions For Safe Operation And Maintenance

6.4 MONITOR FRICTION LOSS

0
30
25
20
15
2.1 psi @ 350 gpm
10
0.1 bar @ 1300 l/min
5
0
0
©Copyright Task Force Tips, Inc. 1999-2017
FLOW (l/min)
750 1525 2300
9.9 psi @ 750 gpm
0.7 bar @ 3000 l/min
200 400 600
FLOW (GPM)
Protector Station Monitor Friction Loss
3030 3800
27 psi @ 1250 gpm
1.8 bar @ 4500 l/min
4.4 psi @ 500 gpm
0.3 bar @ 2000 l/min
800 1000
Fig 6.4
15
4500
2
1
0
1200
LIZ-010 December 26, 2017 Rev12
