- Page 1 Achat 112 passive speaker user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 21.05.2021, ID: 191930 (V2)
-
Page 3: Table Of Contents
Table of contents Table of contents General notes............................... 4 Safety instructions............................. 7 Features............................... 10 Installation..............................11 4.1 Tips on handling speakers......................13 4.2 Hanging the speaker box......................14 4.3 Connections............................15 Technical specifications........................17 Protecting the environment......................19 Achat 112... -
Page 4: General Notes
General notes General notes This user manual contains important information on safe operation of the device. Read and follow all safety notes and all instructions. Save this manual for future reference. Make sure that it is available to all persons using this device. If you sell the device, include the manual for the next owner. - Page 5 General notes Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 6 General notes Warning signs Type of danger Warning – danger zone. passive speaker...
-
Page 7: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 8 Safety instructions WARNING! Consequences of faulty mounting Faulty mounting may lead to lethal injuries or property damage. Please ensure that the norms and regulations valid in your country are always observed when mounting and operating your product. In Germany: BGV C1, “Event and Production Sites for Stage Pre‐ sentations”.
- Page 9 Safety instructions NOTICE! Operating conditions This device has been designed for indoor use only. To prevent damage, never expose the device to any liquid or moisture. Avoid direct sunlight, heavy dirt, and strong vibrations. Only operate the device within the ambient conditions specified in the chapter ‘Technical specifications’...
-
Page 10: Features
Features Features Special features of the device: 2-way passive mid-high speaker with built-in crossover Connection options: 2 lockable NL4 sockets (Power Twist) Flying tracks on top of the housing and an eye on the back for tilting. Mounting for vertical hanging optionally available 36 mm pole flange on the bottom Black textured coating... -
Page 11: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 12 Installation CAUTION! Risk of injury due to heavy weight Due to the heavy weight of the device, at least two persons are required for trans‐ port and installation. NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field.
-
Page 13: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. -
Page 14: Hanging The Speaker Box
Installation 4.2 Hanging the speaker box To hang the speaker box on special mounting devices (aka ‘flying’), the top of the box offers built-in Aeroquip or fly tracks. In these tracks safety eyelets (double studs) can be screwed or latched. Check the secure connection of the safety eyelets with the box carefully, before you use it in ‘flying mode’. -
Page 15: Connections
Installation 4.3 Connections 1, 2 NL4 connections, wired in parallel (INPUT, THRU) Achat 112... - Page 16 Installation NL4 mounting connectors for The drawing alongside shows the pin assignment of the lockable NL4 mounting connectors. speaker connections passive speaker...
-
Page 17: Technical Specifications
Technical specifications Technical specifications Speaker 1 × 12” woofer, 1,4” mid-high speaker Input connections 2 × NL4 sockets (Power Twist) Frequency range 63 Hz … 17 kHz, –10 dB Load capacity 350 W (RMS), 1400 W (peak) Sensitivity (1 W/1 m) 104 dB Rated impedance 8 Ω... - Page 18 Technical specifications Further information Monitor inclination Colour Black Casters Suitable casters optionally available (item no. 243578) Protective cover Suitable protective cover optionally available (item no. 222251) passive speaker...
-
Page 19: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 20 Notes passive speaker...
- Page 21 Notes Achat 112...
- Page 22 Notes passive speaker...
- Page 24 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
