- Page 1 Achat 112 A active speaker user manual...
- Page 2 Musikhaus Thomann Thomann GmbH Hans-Thomann-Straße 1 96138 Burgebrach Germany Telephone: +49 (0) 9546 9223-0 E-mail: info@thomann.de Internet: www.thomann.de 17.06.2021, ID: 325263 (V3)
-
Page 3: Table Of Contents
Table of contents Table of contents General information..........................4 1.1 Further information........................... 5 1.2 Notational conventions........................6 1.3 Symbols and signal words....................... 6 Safety instructions............................. 9 Features............................... 13 Installation..............................14 4.1 Tips on handling speakers......................16 4.2 Hanging the speaker box......................16 Connections and controls........................ -
Page 4: General Information
Our products and user manuals are subject to a process of continuous development. We there‐ fore reserve the right to make changes without notice. Please refer to the latest version of the user manual which is ready for download under www.thomann.de. active speaker... -
Page 5: Further Information
General information 1.1 Further information On our website (www.thomann.de) you will find lots of further information and details on the following points: Download This manual is also available as PDF file for you to download. Use the search function in the electronic version to find the topics of Keyword search interest for you quickly. -
Page 6: Notational Conventions
General information 1.2 Notational conventions This manual uses the following notational conventions: Letterings The letterings for connectors and controls are marked by square brackets and italics. Examples: [VOLUME] control, [Mono] button. 1.3 Symbols and signal words In this section you will find an overview of the meaning of symbols and signal words that are used in this manual. - Page 7 General information Signal word Meaning DANGER! This combination of symbol and signal word indicates an immediate dangerous situation that will result in death or serious injury if it is not avoided. WARNING! This combination of symbol and signal word indicates a pos‐ sible dangerous situation that can result in death or serious injury if it is not avoided.
- Page 8 General information Warning signs Type of danger Warning – suspended load. Warning – danger zone. active speaker...
-
Page 9: Safety Instructions
Safety instructions Safety instructions Intended use This device is designed for sound reinforcement. Use the device only as described in this user manual. Any other use or use under other operating conditions is considered to be improper and may result in personal injury or property damage. No liability will be assumed for damages resulting from improper use. - Page 10 Safety instructions DANGER! Electric shock caused by short-circuit Always use proper ready-made insulated mains cabling (power cord) with a protective contact plug. Do not modify the mains cable or the plug. Failure to do so could result in electric shock/death or fire. If in doubt, seek advice from a registered electrician. DANGER! Electric shock caused by high voltages inside Within the device there are areas where high voltages may be present.
- Page 11 Safety instructions CAUTION! Risk of injury due to heavy weight Due to the heavy weight of the device, at least two persons are required for transport and installation. NOTICE! Risk of fire Do not block areas of ventilation. Do not install the device near any direct heat source. Keep the device away from naked flames. NOTICE! Operating conditions This device has been designed for indoor use only.
- Page 12 Safety instructions NOTICE! Possible staining The plasticiser contained in the rubber feet of this product may possibly react with the coating of your parquet, linoleum, laminate or PVC floor and after some time cause permanent dark stains. In case of doubt, do not put the rubber feet directly on the floor, but use felt-pad floor protectors or a carpet.
-
Page 13: Features
Features Features Special features of the device: 2-way active horn-loaded mid-high speaker with built-in crossover 1/4"-XLR input / output Flying tracks on top of the housing and an eye on the back for tilting. Mounting for vertical hanging optionally available 36 mm pole flange on the bottom Black textured coating Achat 112 A... -
Page 14: Installation
Installation Installation Unpack and check carefully there is no transportation damage before using the unit. Keep the equipment packaging. To fully protect the product against vibration, dust and moisture during transportation or storage use the original packaging or your own packaging material suitable for transport or storage, respectively. - Page 15 Installation CAUTION! Risk of injury due to heavy weight Due to the heavy weight of the device, at least two persons are required for trans‐ port and installation. NOTICE! Possible property damage by magnetic fields Loudspeakers produce a static magnetic field. Therefore, maintain an appropriate distance to devices that can be adversely affected or damaged by an external magnetic field.
-
Page 16: Tips On Handling Speakers
Installation 4.1 Tips on handling speakers We recommend you to set up the speakers in a way, that the sound signals can reach the audi‐ ence unobstructedly. It will often be helpful to mount the speakers on tripods. Thus, the sound will be evenly spread with maximum range throughout the audience area. - Page 17 Installation Using an additional loop on the back of the box, it is possible to tilt the box. This additional loop must not solely be in charge to secure the entire suspended weight. Achat 112 A...
-
Page 18: Connections And Controls
Connections and controls Connections and controls & ä PUSH ö active speaker... - Page 19 Connections and controls 1 [POWER ON/OFF] Main switch to turn the device on and off. 2 [AC INPUT] Blue lockable input socket (Power Twist). 3 [AC OUTPUT] Grey lockable output socket (Power Twist). This output is looped through from the blue input socket [AC INPUT]. You can use it to feed the power supply to the blue input sockets [AC INPUT] of further elements.
- Page 20 Connections and controls 6 [OUTPUT] Line output for connecting further powered speakers, designed as XLR chassis plug. 7 LED [PEAK] Indicates overload. If the LED flickers or is lit, the input signal level is too high. 8 [VOLUME] Volume control. Turn the knob clockwise to increase the volume or counterclockwise to decrease the volume. 9 [TREBLE] Treble control.
-
Page 21: Technical Specifications
Technical specifications Technical specifications Speaker 1 × 12" woofer, 1,4" mid-high speaker Input connections Line 1 × 1/4" jack socket Power supply lockable input socket (Power Twist) Input impedance Line 100 kΩ (balanced), 50 kΩ (unbalanced) Microphone 50 kΩ Output connections Line 1 ×... - Page 22 Technical specifications Signal-to-noise ratio Woofer ≥90 dB (630 Hz, typical) Tweeter ≥88 dB (6.3 kHz, typical) Sound pressure level (SPL), max. 135 dB Impedance 8 Ω Dispersion angle (H × V) 55° × 40° (mid-range transducers) Supply voltage 230 V 50 Hz Dimensions (W ×...
- Page 23 Technical specifications Further information Monitor inclination Bluetooth® USB player Housing Wood Colour Black Protective cover Suitable protective cover optionally available (item no. 222251) Casters Suitable casters optionally available (item no. 243578) Achat 112 A...
-
Page 24: Plug And Pin Assignments
Plug and pin assignments Plug and pin assignments Introduction This chapter will help you select the right cables and plugs to connect your valuable equip‐ ment in such a way that a perfect sound experience is ensured. Please note these advices, because especially in ‘Sound & Light’ caution is indicated: Even if a plug fits into the socket, an incorrect connection may result in a destroyed power amp, a short circuit or ‘just’... - Page 25 Plug and pin assignments Since the interference affects both cores equally, by subtracting the phase-shifted signals, the interfering signal is completely neutralized. The result is a pure signal without any noise inter‐ ference. XLR plug (balanced) Ground, shielding Signal (in phase, +) Signal (out of phase, –) Shielding on plug housing (option) Achat 112 A...
- Page 26 Plug and pin assignments XLR plug (unbalanced) Ground, shielding Signal Bridged to pin 1 active speaker...
-
Page 27: Protecting The Environment
Protecting the environment Protecting the environment Disposal of the packaging mate‐ rial For the transport and protective packaging, environmentally friendly materials have been chosen that can be supplied to normal recycling. Ensure that plastic bags, packaging, etc. are properly disposed of. Do not just dispose of these materials with your normal household waste, but make sure that they are collected for recycling. - Page 28 Notes active speaker...
- Page 29 Notes Achat 112 A...
- Page 30 Notes active speaker...
- Page 32 Musikhaus Thomann · Hans-Thomann-Straße 1 · 96138 Burgebrach · Germany · www.thomann.de...
