A D J U S T A B L E T O P T R A Y
The Adjustable Top Tray gives the ability to refine and
control the weight of the pre-rolls. This tool allows
the operator to lower and raise the funnels in and out
of the paper cones, which will increase or decrease
the overall volume of the pre-rolls.
The RocketBox 2.0 is pre-installed with an Adjustable
Top Tray. The default adjustment is set at at ¼", easily
adjusted with a 7/16" end wrench.
A D J U S T I N G T H E T O P T R A Y
Loosen the bottom nut on the Adjustment Bolt
with a 7/16" closed-end wrench. Repeat with
each of the (6) bottom nuts.
Turn the Adjustment Bolt counter-clockwise to
lower the Top Tray, or clockwise to raise the Top
Tray. Turn each bolt in 1/2 turn increments.
Repeat for all (6) Adjustment Bolts.
Tighten the Adjustment Bolt bottom nut with
7/16 closed-end wrench to secure into place.
Repeat with all (6) bottom nuts.
A D J U S T A B L E T O P T R A Y I S E Q U I P P E D W I T H :
(6) ¼" Adjustment Bolts
(6) ¼" Bottom Nuts
(2) Removable Reset Brackets
R E S E T T I N G T H E T O P T R A Y
Add the (2) Reset Brackets to each side of the
Bottom Tray. Place Adjustable Top Tray on top.
Loosen Adjustable Bolt bottom nut with a 7/16
closed-end wrench. Repeat for all (6) bottom nuts.
Turn the top Adjustment Bolt clockwise (right) until
it touches the Bottom Tray. Tighten the bottom bolt
to lock into place. Repeat with all (6) bolts. This is
the default 1/4" setting.
Ensure all (6) Adjustment Bolts are evenly adjusted.
Tighten bottom nuts to secure into place.
