KTM 790 ADVENTURE '19-
M
O
U
R EF 3 758
1 Person
15 min
EASY
ID
PIEZA/PART
1
2
3
4
5
6
7
8
9
10
11
12
13
N
T
I
N
G
DESCRIPCIÓN
Protector de faro
Soporte superior
Soporte inferior
Silentblock Ø18x Ø9 xØ11 x8
Tope de goma Ø4,5-4,6 x 1,5mm
Tornillo ISO 7380 M4x8 (negro)
Arandela nylon M4
Clip hexagonal M4 Ø3,96 x6,35mm
Tornillo Allen M5x11 Ø11 ISO 7380
Arandela nylon M5x1
Tornillo Allen M5x16 Ø11 ISO 7380
Casquillo Ø8,5 x Ø13 x3,5
Tapón tornillo M5 ISO 7380
www.puig.tv
www.puigusa.com
I
N
S
T
R
HEADLIGH T PR OTEC TO R
DESCRIPTION
Headlight protector
Upper support
Lower support
Ø18x Ø9 x Ø11 x8 silentblock
Ø4,5-4,6 x 1,5mm bumper foot
M4x8 ISO 7380 Allen screw
M4 nylon washer
M4 Ø3,96 x6,35mm exagonal clip
M5x11 Ø11 ISO 7380 Allen screw
M5x1 nylon washer
M5x16 Ø11 ISO 7380 Allen screw
Ø8,5 x Ø13 x3,5 arrowhead
M5 ISO 7380 screw cap
Pg. 1/3
info@puigusa.com
U
C
T
I
O
N
QUICK RELEASE
3'' SECONDS
QTY
1
1
1
4
2
1
1
1
1
2
2
2
1
Illustrations and layout by: www.ciandisseny.com
info@puig.tv
S
Nº 8
TORX
Tº 30
ALLEN
Nº22,5
Nº 2,3
REF
3758WM3
SOPOR2P7-S-3758
SOPOR2P7-I-3758
SILENBGONE--064
TOPEGOMA---3758
ARNV00000000311
CLIP-HEX---3758
ARNV00000000245
TORNI-I7380-493
TAPON--------85
