- Page 1 ITEM NO.：A106005900 WE HAVE YOU IN MIND, LET US HELP YOU! Questions? Issues? CONTACT US 24 hours / 7 days a week www.sunjoyonline.com customer.care@sunjoygroup.com amazon@sunjoygroup com 1-(866)-578-6569 Country of Origin: China Production Number: xxxxxxxxxx...
-
Page 2: Parts List
2 / 7 Parts List Post1 P000200258 Post2 P000200259 Top beam1 P000601186 Top beam 2 P000600812 P000600814 Short small across beam P000600813 Long small across beam Top beam connector2 P000500997 Corner decor P005600135 Post top P000300033 Support P005000224 P000500662 Rail tube connector Tube1 P005700233 Tube 2... -
Page 3: Hardware Pack
3 / 7 Hardware Pack 1 M6*20 Cross hexagonal H02020C11 40 PCS bolt M6 washer H19001C11 72PCS M6*60 hexagonal bolt H02060C11 16PCS M6 Nut H14001C11 16PCS M6 spring washer H13001C11 48PCS M6 wrench H00001C12 2 PCS Country of Origin: China... - Page 4 4 / 7 Fig.1: Put the protect cover(P) through post (A3/A4),then fix the stake plate (Q) to post bottom(A3/A4) by using bolt (AA) and Washer(BB). Fig.2: Attached the post top (G3) to post (A3/A4), set aside. Fig.3-1: Attached the top beam connector 2 (E2) to top beam 2(C) by using bolt (AA), spring washer (LL) and flat wash (BB).
- Page 5 5 / 7 Fig.6: Attached top beam 1 (B5) to the top beam 2 (C), by using the bolt (CC), Spring washer ( LL), flat washer (BB) and nut (DD). Hardware Pack 2 M6 flat washer H19001C11 64 PCS M6*60 bolt H02060C11 32 PCS M6*15 bolt...
- Page 6 6 / 7 Fig.7: Attached the support (H) to the post (A3/A4) and top beam (B5/C), by using bolt (CC), spring washer (LL) and flat washer (BB). Fig.8: Connect the long small across beam (D3) to short small across beam (D2), and fix by using bolt (EE) and flat washer (BB).
-
Page 7: Care And Maintenance
Periodically check and ensure that all bolts are well‐tighten during use. Limited Manufacturer’s Warranty Sunjoy Group warrants to the original purchaser that this item is free from defects in workmanship and materials for 6 months a period of from the date of purchase, provided the item was factory-sealed at the time of purchase and is maintained with care and used only for personal, residential purposes.
