EN
HZ TRANSMIT TER 1 channel
S.A.S. au capital de 5 000 000 E - Z.I. Les Giranaux - BP71 - F70103 A r c - L es-Gray
1s "- - -
a
Programming the transmitter with an existing installation
1.1. Open the memory of the motor using its individual control transmitter:
- Press the Prog. Key for about 3 sec. on the motor's individual contrai transmitter, the motor
rotates by about 0,5 sec in one direction, then in the other.
1.2. Then validate the operation from the new transmitter to be programmed:
- Press the Prog. key for about 1 sec. on the new transmitter, the motor rotates for about 0,5
sec in one direction, then in the other.
- For group contrais from the new transmitter, repeat operations 1.1 and 1.2 for each motor of the group.
- For main contrais from the new transmitter, repeat operations 1.1 and 1.2 for each motor of the installation.
- To delete a transmitter from the memory of a motor, perform operation 1.1 with a programmed transmitter, then perform
m
operation 1.2 with the transmitter to be deleted.
For more complete information about programming, please refer to the instructions of the motor used.
Il
m
Recording and controling intermediate position (P.I.)
Refer to Hz motor instructions to make sure il has this feature.
Recording:
- Move the motor to the wanted
position.
- Press 5 seconds on the STOP key.
The motor will run for 0,5 second in
one direction and then in the other.
D

Technical data

- Compatible with motors & receivers
- Wireless switch/class Ill - Protection Index: IP30
- Maximum transmission lime: 1 O seconds
-Ambient temperature of use : -10T60 (-10'C / +60'C)
- Storage temperature: -30'c to + 70'C
- Transmitter range: 20m throught 2 concrete walls in normal
pollution condition).
- Power: 3V lithium battery typeCR 2430. Lifetime ± 3 years when
4 pressures of 1 s. / day.
Il

Replacement of the battery

0
CE
Simu hereby declares that this product is in ccmpliance with the requirements of Directive 2014/53/EU. The full text of the Declaration of
Conformity is available al www.simu.ccm.
-'k-
-1- •
-
+-: - ','
0%
'
(•)
s1mu-1-1z
technology
2
CE. O EX - RCS VESOUL B 425 650090 • SIRET 425
Controling:
- Press the STOP key for 0,5
second. The motor runs to
the intermediate position.
- Keep away from children
- Do not position the transmitter near metal in order to ensure ils
good working (reduced range).
-A radio appliance using the same frequency (for example
radio headphones) may deteriorate our product's performance.
- Do not immerse the product, avoid splashing of liquids.
- Do not use abrasive products or solvents to clean the product.
- Frequency range: 433,050 MHz - 434, 7 90 MHz F: 433, 4 20 MHz
- Max power used: ERP< 10 mW
- Power supply is not required for saving data.
- Data need not be programmed once again when the cell is
changed.
- Do not recharge the battery.
- Please separate and dispose of the appliance, batteries
and used batteries in a dedicated recycling point.
5122891A
Read carefully these instructions
before any use.
650 090 00011 • n• T.V.A CEE FR 87 425 650 D90
