Step 3.2: Adjust Network Settings - RADAC WaveGuide 5 Direction User Manual

If the WaveGuide system is not connected to the Internet but instead connected to a local
network that includes a time server, then the system can be adjusted to synchronize time
and date with the local time server using the "Set NTP" button and submitting the local
NTP server address.

Step 3.2: Adjust network settings

The network settings can be modified via the web-interface (Fig. 3.4). It is advised to use
the default setting, to automatically obtain the network settings from a DHCP server, and
assure from the side of the DHCP server that the system will receive the same IP-address
at all times. This setting provides the easiest setup and ensures the correct settings for the
local network.
To ensure an accurate system time, the WaveGuide system is by default configured to use
an NTP time service. For this service to work, a connection to the Internet is necessary.
Configuring the use of a static IP could disable the NTP service when the system is not
able to reach any nameserver. The user interface allows to manually add or remove
Figure 3.4: Adjusting the network settings.
Note
Note
nameserver addresses.
19
