The optional mounting frame (product no. WG-MD-SS) consists of three parts connected
to each other by bolts as shown in 1.6. The mounting frame should be installed on two
horizontal beams (the horizontal beams are not included in the mounting frame package).
Note: when designing and producing the horizontal mounting beams, enough horizontal
distance should be left between the radars and the structure they are mounted to. That
is, to prevent reflections (as explained in the beginning of this chapter). If the customer
chooses to design and manufacture a frame, the centers of the mounted radar sensors must
form an equilateral triangle. When installing the radar array it is advised to first install
the mounting frame, and secondly position the three radars.
Radar sensor
Tilt angle [deg]
Min. Signal [dB]
Table 1.1: Advised sensor settings specific to a point array.
A B C
0 15 15
25 25 25
