Cochlear True Wireless Mini Microphone 2 Quick Manual

Cochlear ™ True Wireless
Quick Guide for Cochlear implant users
Features of your Mini Microphone 2 / Mini Microphone 2+
Hear better over a distance and in noisy
listening situations, such as:
in meetings
when travelling by car, bus or train
dining at a restaurant
participating in a class at the gym
How:
Give the Mini Microphone to the person you want to listen to and ask
them to position it close to their mouth by placing it vertically on
their clothing using the clip on the back. Then activate streaming on
your sound processor (see instructions below).
Place your Mini Microphone 2+ on a table to listen to multiple
speakers in a group / conference setting.
Product overview
ON/OFF button
Volume up control
Mute button
Volume down control
Micro-USB connector for
charging (2)
Line input (2+)
™ Mini Microphones
Status indicator (LED)
Clip
Micro-USB connector
for charging (2+)
FM connector (2+)
Up to
25 metres
Place vertically 10-30 cm
between mouth and microphone
Mini Microphone
Mini microphone 2+ used
as a table mic for group
discussions
Getting Started
Charging the battery
When using for the first time, allow your Mini Microphone to
charge for at least 3 hours, even if the light indicates a full charge.
To charge your Mini Microphone:
1. Plug the Micro-USB charging cable into the Mini Microphone.
2. Plug the other end into a power outlet using the supplied
adaptor.
While charging, the LED indicator lights red.
When fully charged (and still connected to the charger), the LED
will turn solid red with green flashes every 2 seconds.
If battery level is low the Status indicator LED will blink yellow once
every second.
On average, the Mini Microphone will operate for up to 10 hours
between charges. Battery life may vary depending on use.
Sound Processor
