USER MANUAL
Model ID: ROGUEOUTCAST1BEAM

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the Rogue Outcast 1 Beam and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Chauvet Professional Rogue Outcast 1 Beam

Summary of Contents for Chauvet Professional Rogue Outcast 1 Beam

  • Page 1 USER MANUAL Model ID: ROGUEOUTCAST1BEAM...
  • Page 2 Rogue Outcast 1 Beam. Trademarks CHAUVET, the Chauvet logo, and Rogue Outcast 1 Beam are registered trademarks or trademarks of Chauvet & Sons, LLC (d/b/a Chauvet and Chauvet Lighting) in the United States and other countries.

  • Page 3: Table Of Contents

    Table of Contents TABLE OF CONTENTS 1. Before You Begin ............... What Is Included ................... Claims ......................Manual Conventions ..................Symbols ......................Expected LED Lifespan................. Safety Notes....................Personal Safety....................Mounting and Rigging ..................Power and Wiring....................Operation ...................... 2. Introduction ................Description ....................
  • Page 4 Table of Contents Setup......................Pan Reverse ...................... Tilt Reverse ......................Pan Angle......................Tilt Angle ......................BL.O. P/T Move....................BL.O. Color Move....................BL.O. Gobo Move ....................Lamp Controls ....................Maintenance Timer .................... Reset Function ....................Factory Reset Function ..................System Information ..................Offset Mode....................

  • Page 5: Before You Begin

    40,000 to 50,000 hours. If extending this lifespan is vital, lower the operating temperature by improving the ventilation around the product, thus reducing the ambient temperature. In addition, limiting the overall projection intensity may extend the LEDs’ lifespan. Page 3 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 6: Safety Notes

    The maximum ambient temperature is 113 °F (45 °C). Do not operate the product at higher temperatures. • In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Page 4 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 7: Introduction

    2. Introduction Description The Rogue Outcast 1 Beam is an IP65 moving head that outputs an intensely bright 300 W beam with 14- position, individually controllable color wheel for solid and split hues. The outdoor-ready unit raises the bar in dynamic effect options with its ability to focus down to a pencil-thin 1° beam for tight aerials, overlapping 8- and 5-facet prisms, frost for even light distribution, and 17 static gobos for even more creative options.

  • Page 8: Product Dimensions

    538 mm 438 mm 4.5 in 144 mm 14.7 in 372 mm 8.9 in 226 mm 4.8 in 121 mm 13.9 in 354 mm 11 in 280 mm Page 6 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 9: Setup

    Always replace the blown fuse with another of the same type and rating. DMX Linking The Rogue Outcast 1 Beam can be linked to a DMX controller using a 5-pin DMX connection. If using other DMX-compatible products with this product, each can be controlled individually with a single DMX controller.

  • Page 10: Gobo Wheel

    ETUP Gobo Wheel The Rogue Outcast 1 Beam includes one gobo wheel with 17 fixed gobos plus open. The diagram shows the gobo number on the wheel as numbered in the DMX Values tables. Open Page 8 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 11: Color Wheel

    ETUP Color Wheel The Rogue Outcast 1 Beam includes one color wheel with 14 fixed colors plus open (white), as indicated below. The diagram shows the color number on the wheel, as numbered in the DMX Values tables. Page 9 of 29...

  • Page 12: Mounting

    Only loosen or tighten the bracket knobs manually. Using tools could damage the knobs. Procedure The Rogue Outcast 1 Beam comes with a double-bracketed yoke to which you can either attach mounting clamps (sold separately) for hanging or simply use as a floor stand. Make sure the clamps are capable of supporting the weight of this product.

  • Page 13: Lamp Replacement

    ETUP Lamp Replacement The Rogue Outcast 1 Beam is equipped with an USHIO NSL 300 W lamp. Follow the procedure below to safely change the lamp. Disconnect the product from power before opening. Procedure Turn the product off and disconnect it from power. Wait at least 15 minutes for the lamp to cool down.

  • Page 14: Increasing The Lamp's Life

    DO NOT touch the lamp without wearing gloves to avoid leaving grease on the bulb or on the contacts that could reduce the lamp’s life. • ALWAYS change the lamp when it has reached its recommended lifespan to avoid the risk of lamp explosion. Page 12 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 15: Operation

    The product will prompt for a passcode to access the product’s main programming level when the control panel lock is activated. Enter the following passcode: <UP>, <DOWN>, <UP>, <DOWN>, <ENTER> Page 13 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 16: Menu Map

    PERATION Menu Map Refer to the Rogue Outcast 1 Beam product page on www.chauvetprofessional.com for the latest menu map. Main Level Programming Levels Description Address 001–497 Sets the starting address 16CH Selects the DMX personality 19CH Auto Test Auto test all functions...
  • Page 17 Shows the amount of time remaining in Remaining Time _ _ _ _ maintenance cycle _ _ _ _ _ _ _ _ _ _ _ _ Shows product UID Page 15 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 18: Dmx Values

    057  060 061  127 Split colors 128  189 Clockwise color scroll, fast to slow 190  193 Stop 194  255 Counterclockwise color scroll, slow to fast Page 16 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 19 000  127 Prism index 128  189 Clockwise rotation, fast to slow Rotating prism 2 190  193 Stop 194  255 Counterclockwise rotation, slow to fast Page 17 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 20 224  231 Effect 28 232  239 Effect 29 240  247 Effect 30 248  255 Effect 31 Movement macro 000  255 Fast to slow speed Page 18 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 21 All reset 210  219 Blackout all function during pan/tilt 220  229 Disable blackout all function during pan/tilt 230  239 Lamp off 240  255 No function Page 19 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 22: 16Ch

    057  060 061  127 Split colors 128  189 Clockwise color scroll, fast to slow 190  193 Stop 194  255 Counterclockwise color scroll, slow to fast Page 20 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 23 000  127 Prism index 128  189 Clockwise rotation, fast to slow Rotating prism 2 190  193 Stop 194  255 Counterclockwise rotation, slow to fast Page 21 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 24 All reset 210  219 Blackout all function during pan/tilt 220  229 Disable blackout all function during pan/tilt 230  239 Lamp off 240  255 No function Page 22 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...

  • Page 25: Address

    Select YES (reverse tilt) or NO (normal tilt), press <ENTER>. Pan Angle This option assigns pan range. Highlight Pan Angle, press <ENTER>. Select 540, 360, or 180, press <ENTER>. Page 23 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 26 This option sets the duration of time (seconds) it takes for the lamp to turn on when powering up the product. Highlight Ignition Delay, press <ENTER>. Select 0–255, press <ENTER>. Page 24 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 27 Select YES or NO, press <ENTER>. All Reset This option resets the all the functions to the home position. Highlight All, press <ENTER>. Select YES or NO, press <ENTER>. Page 25 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 28 Lamp Power: The lamp’s power is displayed on the screen. • Fan Speed: The product’s fan speed is displayed on the screen. • UID: The product’s UID is displayed on the screen. Page 26 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 29 Highlight MAC4, press <ENTER>. Select 000–255, press <ENTER>. Mac 5 Highlight MAC5, press <ENTER>. Select 000–255, press <ENTER>. Mac 6 Highlight MAC6, press <ENTER>. Select 000–255, press <ENTER>. Page 27 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 30 Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Do not spin the cooling fans while blowing compressed air into them. Page 28 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 31 I/O Connector Channel Range 5-pin XLR 16 or 19 Ordering Product Name Item Code UPC Number Rogue Outcast 1 Beam 25011676 781462220242 UL 1573 CSA C22.2 No. 166 E113093 Page 29 of 29 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 32 Be sure to pack the product properly. Any shipping damage resulting from inadequate packaging will be your responsibility. FedEx packing or double-boxing are recommended. Chauvet reserves the right to use its own discretion to repair or replace returned product(s). Page 30 of 31 Rogue Outcast 1 Beam User Manual Rev. 1...
  • Page 33 Visit the applicable website above to verify our contact information and instructions to request support. Outside the U.S., U.K., Ireland, Mexico, France, Germany, or Benelux, contact the dealer of record. Page 31 of 31 Rogue Outcast 1 Beam User Manual Rev. 1...
