Location - Stuart Turner MAINBOOST iTank MBI Series Installation, Operation & Maintenance Instructions Manual

2 LOCATION - GENERAL
2.11
2.12 Protection: The iTank must be located in a dry, frost free area.
2.13 Heat sources: Separate the iTank from other appliances that
2.15 Water retention: Site the iTank in a location where in the unlikely
2.16 Supply inlet pressure: The water supply inlet pressure must be at least 0.2 bar
and no greater than 10 bar; lower supply inlet pressures will reduce the tank
fill rate and reduce the time the iTank will run at higher flow rates before
running out of stored water.
2.17 Ambient temperature: The iTank must be sited in a location where the
ambient temperature does not exceed 30
Section 7.13 - Water Quality).
2.18 Pipework: For optimum performance outlet pipework must be 21 mm/¾ "
pipe. Pipework should only reduce to 15 mm/½ " when entering terminal
fittings.
2.19 Static outlet pressure: The static outlet head must also be within the
maximum requirement of 12 metres (vertically above the appliance).
2.20 Noise: A flexible hose is supplied as standard which will minimise the
transmission of noise and vibration from the iTank pump to the pipework
connected to the appliance outlet. However, care must be taken when
mounting the iTank that any noise is not amplified through loose panels or
pipework.
2.21 Direction of flow: Ensure the water flow is in the direction of the arrow
marked on the control module.
2.22 Flexible hose: Only use the Stuart Turner hose supplied with the pump.
2.23 Isolating valves: Separate system isolating valves (non restrictive) must be
fitted to allow easy pump service. Isolating valves must be mounted where
specified to allow the system isolation and removal of the iTank if needed.
See Section 4 for installation details.
Access: For emergencies and maintenance the pump must be
easily accessible.
generate heat.
event of a water leak, any spillage is contained or routed to avoid
electrics or areas sensitive to water damage. Drip trays are
available for each model to protect from leaks and condensation. If
the unit is intended for use in an attic space or above any critical
area then a drip tray should be fitted (optional accessory avaiable).
C or below 4
o
- 7 -
C (see
o
Cont ...
