MAINSBOOST
Mainsboost Installation, Operation &
Maintenance Instructions
Please leave this instruction booklet with the home owner as it contains
important warranty, maintenance and safety information
Read this manual carefully before commencing installation.
This manual covers all Mainsboost vertical composite vessels.
5
WARRANTY
CE compliant product
- 1 -
Advertisement
Table of Contents
Related Manuals for Stuart Turner MAINSBOOST MB 100CV
Summary of Contents for Stuart Turner MAINSBOOST MB 100CV
- Page 1 MAINSBOOST Mainsboost Installation, Operation & Maintenance Instructions Please leave this instruction booklet with the home owner as it contains important warranty, maintenance and safety information Read this manual carefully before commencing installation. This manual covers all Mainsboost vertical composite vessels. WARRANTY CE compliant product - 1 -...
-
Page 2: Table Of Contents
PRODUCT DESCRIPTION Mainsboost consists of one key assembly, the Mainsboost vessel complete with upstream line-in kit. APPLICATION Mainsboost is designed to offer stored clean, potable cold water under pressure for all domestic or small commercial applications where mains water is insufficient to offer consistent and reliable water services. - Page 3 WARNINGS: Mainsboost systems must not be used for any other application without the written consent of Stuart Turner Limited. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and understand the hazards...
-
Page 4: Checklist
IMPORTANT: Your Mainsboost water performance system will be delivered in a minimum of two boxes on one pallet. Please check the contents within 24 hours of receipt and if any component is damaged, please contact Stuart Turner Ltd immediately. Package 1a Monobloc 22/28mm Upstream line-in kit Fig. -
Page 5: Introduction
Trademarks & Trade Names ‘Mainsboost’ ‘Mainsboost Plus’ and ‘Mainsboost Charger’ are registered Trademarks of Stuart Turner Ltd. How the Mainsboost System works The Mainsboost vessel stores water from the rising main in a sealed water chamber, separated from the air space by a rubber diaphragm and pressurised to an optimum setting. -
Page 6: Important Facts Read Before Commencing Installation
2 IMPORTANT FACTS READ BEFORE COMMENCING INSTALLATION A Water temperature This unit is designed for cold water applications only which should not exceed the following values: 2.11 The maximum allowable water temperature is 35 2.12 The minimum allowable water temperature is 4 B Pipework - General 2.13 Secure pipework: Ensure pipework to and from the Mainsboost is independently supported &... -
Page 7: Location
5 bar. (If mains pressure is below 2.0 bar the Mainsboost vessel should be supplemented with a pump unit, contact Stuart Turner for details). 3.14 Ensure that location of the unit allows adequate space to give reasonable access to all parts to accommodate service/commissioning. -
Page 8: Terminology
4 TERMINOLOGY 4.11 Upstream Line-in Kits (ULK) Monobloc upstream line-in kit: The Mainsboost Monobloc is a patent pending mains regulating device and should be installed on the rising main between the stopcock and the Mainsboost vessel. The Monobloc unit is used on 22mm or 28mm upstream line in kits. -
Page 9: Configuration
5 CONFIGURATION 5.11 Mainsboost is a very flexible solution, offering a packaged system to suit any type or size of building no matter how large or small the demand. The following illustrations depict some of the most typical installations. 5.12 Single occupancy application Use of Mainsboost in a house offers water on demand whilst giving maximum flexibility. - Page 10 Note: If a water softener is to be fitted it must be located between the upstream line-in kit and the vessel. If high pressure is also required to the drinking tap fit a Stuart Water Conditioner, available from Stuart Turner, rather than a water softener.
-
Page 11: Installation
6 INSTALLATION Step 1: Remove the Mainsboost vessel from its packaging and check to ensure it is not damaged. WARNING: depending on vessel size this may require two people to complete safely. Ensure the floor is sufficiently strong enough to take the total weight of the unit when full of water (see Technical Specification section). - Page 12 Note: Do not forget if a water softener is to be installed this has to be included in this pipe run, and additional space must be allocated for this. Do not fit smaller pipework than the upstream line-in kit accepts as this will impair performance.
- Page 13 Note: Do not forget if a water softener is to be installed this has to be included in this pipe run, and additional space must be allocated for this. Do not fit smaller pipework than the upstream line-in kit accepts as this will impair performance.
-
Page 14: Commissioning
If static mains pressure is less than 2 bar a pumped unit < 2.0 will be required - consult Stuart Turner 2.5** 2.5* *Adjust pressure regulating valve down to these settings where possible. **Recommended setting. -
Page 15: Technical Specification
286.0 488.5 22 or 28 Stuart Turner reserve the right to amend the specification in line with its policy of continuous development of its products. *Note: The maximum pressure that can be applied to the pump under any installation conditions. -
Page 16: Trouble Shooting
5.0 bar, adjust to suit. Note: Mains supply pressure gauge reading has to exceed desired pressure on PRV System works but runs Insufficient vessel Call Stuart Turner on +44 (0) 800 31 969 80 out of water capacity - 16 -... -
Page 17: Warranty
10 YOUR WARRANTY Congratulations on purchasing a Stuart Turner Mainsboost system. We are confident this product will give you many years of trouble free service as all our products are manufactured to the very highest standard. Mainsboost vessels are warrantied for five years, fittings including the Mainsboost Monobloc and other ULK components are warrantied for 2 years. - Page 18 NOTES - 18 -...
- Page 19 NOTES - 19 -...
- Page 20 Signed ..........Stuart Turner are an approved company to BS EN ISO 9001:2015...
