Stuart Turner MAINBOOST iTank MBI Series Installation, Operation & Maintenance Instructions Manual page 13

4.13 Stage 3 - Final Assembly:
Step 1
Install the provided 1 1/4" overflow using the included overflow washer and
nut (Fig. 13a) and the 1/2" compression adaptor to the inlet valve which
should be sealed using suitable thread sealant or PTFE tape (Fig. 13b).
Overflow
nut
Step 2
Connect pressure vessel to control module using included G ¾ hose and
washers (Fig. 14).
G ¾ washer
G ¾ hose
Overflow
Overflow
washer
Fig. 13a
Inlet valve
compression adaptor
Fig. 14
G ¾ washer
- 13 -
Fig. 13b
Pressure vessel
Cont ...
