Anchor Xtreme XTR-6000CU2 Owner's Manual

HAVING TROUBLE W/ YOUR SOUND SYSTEM?

CONDITION POSSIBLE CAUSE
No Sound (power LED = OFF) • power switch is in OFF position
• blown fuse
No Sound (power LED = ON) • no output from source
• input cable unplugged
• input volume control low or off
• accessory or expansion module not in option bay
Distorted Sound • poor or improper connection on input cable
• input signal too strong
Excessive Hum or Noise • input cable not shielded
• not using balanced microphone
HAVING TROUBLE W/ YOUR WIRELESS SYSTEM? (Wireless Models Only)
CONDITION POSSIBLE CAUSE
No Sound (TX ON indicator lights) • wireless volume control low or off
• no mic plugged into belt-pack transmitter
No Sound (TX ON indicator off) • sound system not turned on
• transmitter power switch turned off
• low battery or no battery in transmitter
Anchor Audio Customer Service
888-444-6077

XTREME TECHNICAL SPECIFICATIONS

Rated Power Output 130 watts
Max SPL @ Rated Power 123 dB Projection ON
116 dB Projection OFF
Frequency Response 80 Hz – 15 kHz Proj OFF
7 dB – 2-12 kHz Proj ON
Bass/Treble Control 8 dB cut/boost @ 100 Hz, 8 kHz
AC Power Reqs. 110 – 125Vac, 50/60 Hz, 250W Max
210 – 240Vac, 50/60 Hz, 250W Max
Dimensions (HWD) 22.5 x 13 x 10" / 57 x 33 x 25 cm
Weight 35 pounds / 16 Kg
(Specifications subject to change without notice)
Anchor Audio, Inc.
Portable Sound Systems • Torrance, California
Inputs
Line 1/4" phone, Hi-Z, unbalanced
Mic (phantom power) XLR female, Lo-Z, 12 VDC
Balanced XLR female, switchable mic/line level
12 VDC phantom power (switchable)
Sensitivity For Rated Output
Line (unbalanced) -18 dBV (125 mVrms)
Mic (balanced) -58 dBV (1.25 mVrms)
Line (balanced) -15 dBV (175 mVrms)
Outputs
Line (post fader) XLR male, 600ohm, active balanced
Speaker 4-pole Neutrik Speakon® jack
Xtreme
Portable Sound System
OWNER'S MANUAL
Getting Started - WARRANTY INFORMATION .................................................................................................. 2
Setting Up Your Xtreme Sound System ......................................................................................................... 2
Feedback - Connecting Xtreme Sound Systems - Speaker Stand Setup ................................................ 3
Sound System Accessories ............................................................................................................................... 4
XTREME SOUND SYSTEM BASIC OPERATION ...................................................................................................... 4/5
Operating The Built-In Uhf Wireless Receiver ........................................................................................... 6
Operating The Built-In Cd Player .................................................................................................................. 6
Operating The Wireless Microphone/Transmitter ................................................................................... 7
HAVING TROUBLE W/ YOUR SOUND SYSTEM? ...................................................................................................... 8
XTREME TECHNICAL SPECIFICATIONS .................................................................................................................... 8
100-0135-000/B- 10/06
CONTENTS
