Chapter 6

Setting channel levels

This chapter explains how to set channel levels for conventional lights and
color scrollers. For information on setting attribute levels for ML fixtures,
see
Chapter 9 Setting ML attribute levels, page

Selecting channels

Using the keypad to set channel levels involves two steps: selecting the
channels, then entering output levels.
To select a single channel, enter the channel number, press: [1].
To select two channels, enter the first channel, then press [+] and
enter the second channel, press: [1] [+] [7].
To select a group of consecutively numbered channels, enter the
number of the first channel, then press [Thru] and enter the last
number, press: [1] [Thru] [9].
To select all but one of a group of consecutively numbered channels,
enter the first channel, press [Thru], enter the last channel, then press
[–] and enter the channel to leave out, press: [1] [Thru] [9] [–] [5].
Once you have entered your channel selections, you are ready to set
channel levels.

Selecting channels with Flexichannel active

Working with Flexichannel active differs from working without
Flexichannel in only one respect, selecting channels with [Thru].
In All Channels mode, pressing [1] [Thru] [5] [Enter] selects all channels
from 1 to 5. When Flexichannel is enabled, the [Thru] key functions slightly
differently. In Show Channels, Current Channels or View Channels mode,
pressing [1] [Thru] [5] [Enter] selects all visible channels from 1 to 5.
To select all channels from 1 to 5, visible or hidden, press [1] [Thru] [Thru]
[5] [Enter].
18.
If the first channel in the selected range is unused, you don't need to use [Thru]
[Thru].
18
109.
Obsession II User Manual, v.4.4
63
