- Page 1 Form 04581351 Edition 2 April 2005 Fixtured In-Line DC Electric Nutrunner Maintenance Information Save These Instructions...
-
Page 2: General Instructions
Wipe clean the Spindle Assemblies with a clean, dry and lint-free rag. Once gear case is clean, apply prescribed amounts of Work 2.5 cc of Ingersoll-Rand #222 grease into the inner diameter Ingersoll-Rand #222 Grease as follows: of the Coupler (9). -
Page 3: Spindle Assembly
Housing (3). mounted with the plate spacer in place, the tool can be assembled by Work 2.5 cc of Ingersoll-Rand grease 222 into the inner diameter of following the first set of instructions (A). The reason for the plate spacer the Coupler (9). - Page 4 Mounting Options (Dwg. 80149735) (Dwg. 80150675) There are two options for mounting tools. 1) When fixture is between Spindle and Transducer (Y), remove and 2) When Fixture Plate (X) is in front of Spindle Flange, Spacer Plate (Z) discard Spacer Plate (Z). thickness may be ignored: Note: Fixture Plate (X) must maintain thickness of Spacer Plate (Z).
- Page 5 Notes Form 04581351-Edition 2...
- Page 6 Notes Form 04581351-Edition 2...
- Page 7 Notes Form 04581351-Edition 2...
- Page 8 Ingersoll-Rand © 2005 Company...
