Orange Pi Plus User Manual
Low-level peripherals
GPIO(1x3) pin
LED
Key
Supported OS
Interface definition
Product size
Weight
Orange Pi™ is a trademark of the Shenzhen Xunlong Software CO., Limited
Hardware
Top view:
www.orangepi.org
40 Pins Header,compatible with Raspberry Pi B+
UART, ground.
Power led & Status led
IR input, UBOOT, POWER
Android, Ubuntu, Debian, Rasberry Pi Image
108 mm × 60mm
50g
Shenzhen Xunlong Software CO., Limited
www.xunlong.tv
