Orange Pi Plus User Manual

Hardware specification

CPU
GPU
Memory (SDRAM)
Onboard Storage
Onboard Network
Onboard WIFI
Video Input
Audio Input
Video Outputs
Audio Output
Power Source
USB 2.0 Ports
Buttons
www.orangepi.org
H3 Quad-core Cortex-A7 H.265/HEVC 4K
Mali400MP2 GPU @600MHz, Supports OpenGL ES 2.0
1GB DDR3 (shared with GPU)
TF card (Max. 64GB) / MMC card slot , up to 2T on 2.5 SATA disk
8GB EMMC Flash
10/100/1000M Ethernet RJ45
Realtek RTL8189ETV, IEEE 802.11 b/g/n
A CSI input connector Camera：
Supports 8-bit YUV422 CMOS sensor interface
Supports CCIR656 protocol for NTSC and PAL
Supports SM pixel camera sensor
Supports video capture solution up to 1080p@30fps
MIC
Supports HDMI output with HDCP
Supports HDMI CEC
Supports HDMI 30 function
Integrated CVBS
Supports simultaneous output of HDMI and CVBS
3.5 mm Jack and HDMI
DC input can supply power, but USB OTG input don't supply power
Four USB 2.0 HOST, one USB 2.0 OTG
Power Button(SW4), Recovery Button(SW2), Uboot Button(SW3)
