- Page 1 Invacare® Birdie® EVO Birdie® EVO, Birdie® EVO COMPACT, Birdie® EVO PLUS, Birdie® EVO XPLUS en Mobile Patient Lift User Manual This manual MUST be given to the user of the product. BEFORE using this product, this manual MUST be read and saved...
- Page 2 All rights reserved. Republication, duplication or modification in whole or in part is prohibited without prior written permission from Invacare. Trademarks are identified by ™ and ®. All trademarks are owned by or licensed to Invacare Corporation or its subsidiaries unless otherwise noted.
-
Page 3: Table Of Contents
Contents 7.3 Folding the mast ....... 25 7.4 Mast extension for upright positioning....25 8 Maintenance . -
Page 4: General
Note that there may be sections in this document, which are not relevant to your product, since this document applies Invacare accepts no liability for damage arising from: to all available models (on the date of printing). If not otherwise stated, each section in this document refers to all •... -
Page 5: Safety
If you are – See 11.4 Environmental conditions, page 32. unable to understand the warnings, cautions or instructions, contact a healthcare professional, Invacare provider or qualified technician before WARNING! attempting to use this product. Risk of injury or damage –... -
Page 6: Safety Information On Accessories
To prevent, reduce or eliminate – Due to regional differences, refer to your such electromagnetic interference: local Invacare website or catalog for available – Only use original cables, accessories and spare accessories or contact your Invacare provider. -
Page 7: Labels And Symbols On The Product
Safety 2.4 Labels and symbols on the product Class II equipment 2.4.1 Label Location Type B applied part WEEE conform European Conformity Medical device Abbreviations for technical data: • Iin = Incoming Current • AC = Alternating Current • Uin = Incoming Voltage •... - Page 8 Invacare® Birdie® EVO Humidity limitation Atmospheric pressure limitation Transport and storage conditions Always ensure that the sling is properly attached to the hooks. Operation conditions See 6.2.1 Attaching the sling to the lift, page 20. 60128520-A...
-
Page 9: Product Overview
All position changes are possible without assistance of the Due to regional differences, refer to your local patient. Invacare website or catalog for details about available accessories or contact your Invacare provider. There are no known contraindications for this product. -
Page 10: Setup
Risk of Injury and washing instructions. Improper assembly may cause injury or damage. – Use only Invacare parts in the assembly of this patient lift. 4.3 Installing the mast – After each assembly, check that all fittings... -
Page 11: Assembling The Mast To The Base
Setup 1. Lock both rear castors B. Remove the locking pin A. 2. Raise the mast assembly C to an upright position by stepping with one foot on the leg D and pulling the push bar E upwards until the safety catch F snaps in place. Lock both rear castors B and rotate the hand screws anti-clockwise A to remove them from the base Reinstall the locking pin A through the mast G and... -
Page 12: Installing The Actuator To The Boom
Invacare® Birdie® EVO 1. Release the D-clip and remove the pin A from actuator 2. Remove the actuator B from the bracket on the mast and fit it to the boom mounting bracket C. Push and hold the boom C towards the mast D and fold down the spreader bar holder E. -
Page 13: Resetting The Service Indicator
3. You will hear a sound when the service indicator has been reset. (CBJ Care control unit only) IMPORTANT! If the service light is flashing yellow during daily usage or after a reassembly, the lift requires service. – Contact your Invacare provider for service. 60128520-A... -
Page 14: Usage
The hand control is used to open or close the legs of the assistants. base. – Invacare recommends that the rear castors be left unlocked during lifting procedures to 1. To close the legs, press allow the patient lift to stabilize itself when the... -
Page 15: Emergency Functions
Usage Removing the spreader bar 5.6.3 Activating an emergency lowering (CBJ Care, CBJ1, CBJ2 control unit) If the hand control fails, the boom can be lowered by using 1. Push and hold the release button up. the circular switch for emergency release. Use a sharp 2. -
Page 16: Charging The Battery
Invacare® Birdie® EVO Birdie® EVO and Birdie® EVO PLUS / XPLUS patient is still possible. It is recommended to charge the batteries as soon as the sound signal is heard. 1. Locate the red emergency grip A at the bottom of the actuator piston. -
Page 17: Optional Hand Control
Usage CBJ Care Battery Battery Description Indicator State Battery Battery Description Type Indicator State Type Full The battery is OK — no need Charge for charging (100–50%). The Full The battery is OK — no need right LED is GREEN. Charge for charging (100–50%). - Page 18 Invacare® Birdie® EVO 1. Place the battery B When the battery is placed on the charger, the charge on the control unit or LED will illuminate. When charging is complete, charge LED will switch off. charger as shown and make sure there is an A battery needing to be fully recharged will take audible click.
-
Page 19: Patient Transfer
– Use the push bars on the mast at all times to possible. push or pull the lift. – Avoid using the lift on an incline. Invacare recommends that the product only be used on 6.2 Preparing to lift a flat surface. -
Page 20: Attaching The Sling To The Lift
3. Repeat the steps for each of the remaining straps of patient to fall or cause injury to assistants. the sling. – Use an Invacare approved sling that is recommended by the individual’s doctor, nurse or medical assistant for the comfort and safety of the individual being lifted. -
Page 21: Transferring A Patient To A Bed
Patient Transfer Lower the patient so that his/her feet rest on the base of the lift, straddling the mast. Lift the patient high enough to clear the stationary The lower center of gravity provides stability object with their weight fully supported by the lift. making the patient feel more secure and the lift The boom will stay in position until the DOWN easier to move. -
Page 22: Transferring A Patient From A Wheelchair
Raise the boom until there is tension on the straps of the The Invacare patient lift is NOT intended as a sling and make sure that the sling is properly attached transport device. If the bathroom facilities are NOT to the hooks of the spreader bar. -
Page 23: Lifting A Patient From The Floor
Lower the patient onto the commode, leaving the sling attached to the spreader bar hooks. Invacare recommends that the sling remains connected to the spreader bar hooks during the patient’s use of either the commode chair or standard commode. - Page 24 Invacare® Birdie® EVO Position the lift with one leg under the patient’s bent Attach the sling. See 6.2.1 Attaching the sling to the knees and the other leg under the patient’s head. Keep lift, page 20. the sling straps inside of the legs of the lift.
-
Page 25: Transportation And Storage
6. Reverse the procedure described in 4.3.1 Unfolding the mast, page 10 and pull and hold the safety catch F upwards before folding down the mast. The folded lift can now be placed in an upright position. 7.4 Mast extension for upright positioning (Birdie EVO only) 60128520-A... -
Page 26: Maintenance
– The product does not tolerate cleaning in – If the service light is flashing yellow the lift requires automatic washing systems, with high-pressure service. Do not use the lift and contact your Invacare cleaning equipment or steam. provider for service. -
Page 27: Disinfection Instructions
Risk of injury or damage online.de/en/for-users. Service must be performed only by a qualified technician. – Contact your Invacare provider for service. In Domestic Care Service must be performed at least every 12 months unless Method: Follow the application notes for the used otherwise stated in local requirements. -
Page 28: After Use
Invacare® Birdie® EVO Be environmentally responsible and recycle this product 9 After Use through your recycling facility at its end of life. Disassemble the product and its components, so the different 9.1 Disposal materials can be separated and recycled individually. -
Page 29: Troubleshooting
The control unit emits a beeping sound Max. load is exceeded Reduce the load (and the lift will during lifting, and the motor stops. function normally). Contact your Invacare provider if the above does not solve your problems. 60128520-A... -
Page 30: Technical Data
Invacare® Birdie® EVO 11 Technical Data 11.1 Maximum safe working load Birdie® EVO Birdie® EVO Birdie® EVO Birdie® EVO COMPACT PLUS XPLUS Max. Safe Working Load (patient + spreader bar + sling) 180 kg 150 kg 180 kg 210 kg 11.2 Dimensions and Weights... -
Page 31: Electrical System
Technical Data Dimensions [mm] Birdie® EVO Birdie® EVO Birdie® EVO COMPACT PLUS / XPLUS Total width (legs closed), external measure Min. internal width (i) Internal width at maximum reach (k) Turning diameter without lever 1400 1400 1210 1210 1430 Turning diameter with lever 1400 1400 1245... -
Page 32: Environmental Conditions
Invacare® Birdie® EVO Birdie® EVO Birdie® EVO Birdie® EVO COMPACT PLUS / XPLUS Applied part complying with the specified requirements for Type B Applied Part protection against electrical shock according to IEC60601-1. Sound level 45 – 50 dB(A) Working ability 40 full lifts (with battery between 100% –... -
Page 33: Electromagnetic Compatibility (Emc)
Electromagnetic compatibility (EMC) 12 Electromagnetic compatibility (EMC) 12.1 General EMC information Medical Electrical Equipment needs to be installed and used according to the EMC information in this manual. This product has been tested and found to comply with EMC limits specified by IEC/EN 60601-1-2 for Class B equipment. Portable and mobile RF communications equipment can affect the operation of this product. - Page 34 Invacare® Birdie® EVO Immunity test Electromagnetic environment – guidance Test / Compliance level < 0% U for 0,5 cycle at Voltage dips, short Mains power quality should be that of a typical commercial or hospital 45° steps interruptions and environment. If the user of this product requires continued operation during...
- Page 35 Notes...
- Page 36 Italia: Nederland: Belgium & Luxemburg: Norge: Invacare AS Invacare Mecc San s.r.l., Invacare BV Invacare nv Grensesvingen 9, Postboks 6230, Via dei Pini 62, Galvanistraat 14-3 Autobaan 22 Etterstad I-36016 Thiene (VI) NL-6716 AE Ede...
