Spare Parts - Rehasense SERVER Service Manual

7 Spareparts
General
7.1
Pos
Complete push handle set with tube for L size
1
Complete push handle set with tube for M size
Complete push handle set with tube for S size
2 Complete plastic push handle
Brake cable:d5.0x1000-d1.5x1155mm for L-size
3
Brake cable,d5.0x840mm-d1.5x995mm for rollator M,S size
4 Brake block set ; left + right side as one set
Complete cross brace for L size
5
Complete cross brace for M size
Complete cross brace for S size
Complete locking mechanism for cross brace for L size
6
Complete locking mechanism for cross brace for M size
Complete locking mechanism for cross brace for S size
7 Shafts for shopping basket (set of 2)
8 Lock system shaft assembly
9 Black seat with pull strap and rings
10 Black step pedal
11 Front wheel
12 Rear wheel
13 Black front fork
14 Front piece set
Issue 11 / 2016
Art. No.: SM00002EN
Description
Article No.
Qty
Left Right
ROL1E3-RS ROL1DZ-RS
2
ROL1E4-RS ROL1E1-RS
ROL1E5-RS ROL1E2-RS
ROL1DL-RS ROL1DK-RS 2
69100X-RS
2
69100Z-RS
ROL1DR-RS 2
ROL1DS-RS
ROL1DT-RS 1
ROL1DU-RS
ROL1DW-RS
ROL1DX-RS 1
ROL1DY-RS
ROL20W-RS 1
ROL20A-RS 1
ROL10F-RS 1
ROL117-RS 2
ROL30H-RS 2
ROL30J-RS 2
ROL11Z-RS 2
ROL1EW-RS 2
4/14
