0 Content
1. Cleaning

2. Technical data

3. Maintenance
4. Refurbishment
5. How to deposit the product
6. Warranty
7. Spare parts
8. Exchange of spare parts – instructions
1 Cleaning
General:
Clean the device regularly and keep it clean.
•
Lighter dirt and dust can be removed with a wet cloth.
•
Larger parts of dirt can be removed with a non-corroding, mild washing agent and warm water.
•
• Do not use harsh abrasives or bleach based cleaners, as this may cause damage or discolouration.
• Dry parts with a soft cloth.
Wheels:
Clean wheels with warm water and a mild cleanser. Dry with a clean rag.
•
• Lubricate with multi-purpose oil periodically or if wheels begin to squeak.
Wheel axles:
The area between the fork and the front wheel should be kept clean, because dirt and hair
•
accumulating there and can cause faster wear of caster bearings.
To do so, one should disassemble the front caster by disassembling it from the fork (according to
•
the instruction in paragraph 8.12), to remove all dirt, and then preserve the metal elements of the
wheel (i.e. to apply technical grease).
Brakes:
• If not working correctly the brakes should be adjusted according to the instructions
in paragraph 8.4.
2 Technical data
Size
Max. load
Max. load of the bag
Total weight without shopping bag
Shopping bag
Length
Total height folded (lowest)
Width opened
Width folded
Seat Width
Height of hand grips (adjustable)
Height of seat
Brakes
Wheels (diameter x width)
Issue 11 / 2016
Art. No.: SM00002EN
„SERVER" light weight rollator
Small
150 kg
5 kg
6,6 kg
0,3 kg
66 cm
72 cm
60,8 cm
22,5 cm
46 cm
63 – 79 cm
50 cm
20,2 x 3,5 cm
2/14
Medium
150 kg
5 kg
6,7 kg
0,3 kg
66 cm
74 cm
60,8 cm
22,5 cm
46 cm
66 – 86 cm
55 cm
2 handbrakes with locking function
20,2 x 3,5 cm
Service Manual Server ENG
Large
150 kg
5 kg
7,0 kg
0,3 kg
66 cm
79 cm
60,8 cm
22,5 cm
46 cm
74 - 102 cm
62 cm
20,2 x 3,5 cm
