Freestanding Gas Cookers - 50 & 60cm
SCG50W/SCG60W/TCG50W/TCG60W
Please read these instructions carefully before attempting to install or use this appliance.
We recommend that you keep these instructions in a safe place for future reference.
Installation and Operating Instructions
Advertisement
Subscribe to Our Youtube Channel
Related Manuals for montpellier SCG50W
Summary of Contents for montpellier SCG50W
- Page 1 Installation and Operating Instructions Freestanding Gas Cookers - 50 & 60cm SCG50W/SCG60W/TCG50W/TCG60W Please read these instructions carefully before attempting to install or use this appliance. We recommend that you keep these instructions in a safe place for future reference.
- Page 2 Welcome Thank you for choosing this Montpellier Freestanding Gas Cooker. Our Cookers has been designed to provide you with the best combination of style, reliability and performance to give you years of trouble-free use. You may be familiar with a similar product, but please take time to read these instructions carefully before installing or using your Freestanding Cooker to ensure you get the most from your purchase.
- Page 3 Dear Customer, Pieces of packaging (plastic bags, polystyrene etc.) must not be left within reach of children, as they are potentially dangerous. Please dispose of packaging thoughtfully by the appropriate means. To this effect, we recommend that you read the entire guide carefully before operating the product and keep it as a reference.
- Page 4 IMPORTANT WARNINGS • WARNING: This appliance must be earthed! • Ensure that the electricity supply is turned OFF before installing your appliance. • Ensure that the appliance is switched off before replacing the oven lamp. If the supply cord is damaged, it must be replaced by the •...
- Page 5 • Do not splash cool water in an oven tray or inside the oven when the surface of the appliance is still hot. Arising Steam may cause burns and a sudden temperature exchange may cause damage to the surface of the appliance •...
- Page 6 • If the product has a digital timer, you must reset after a loss of power. Otherwise, your oven will not operate. • Caution: Accessible parts may be hot when the grill is in use. Young children should be kept away” •...
- Page 7 • WARNING: Danger of fire: Do not store items on the cooking surfaces. TECHNICAL FEATURES OF YOURCOOKER SPECIFICATIONS 50 x 50 50 x 60 60 x 60 500 mm 500 mm 600 mm Outer width 600 mm 660 mm 660 mm Outer depth Outer height 850 mm...
- Page 9 INSTALLATION OF YOUR COOKER GAS CONNECTION CAUTION: THIS APPLIANCE MUST ONLY BE INSTALLED IN A PERMANENTLY VENTILATED ROOM IN COMPLIANCE WITH THE APPLICABLE REGULATIONS and by a qualified engineer. It shall be installed and connected in accordance with current installation regulations. Particular attention should be given to the relevant requirements regarding ventilation.
- Page 10 Connection and Security: 1. Prior to installation, ensure that the gas supply (type of the gas and gas pressure) and the adjustment of the appliance are compatible 2. The adjustment conditions for this appliance are stated on the label (or rating plate and are specified in this booklet) 3.
- Page 11 9. Please use a flexible hose for gas connection. 10. Connect your cooker to the LPG supply by shortest route and without any leak. Min. 40 cm Max. 125 cm. 11. When making gas leak test, never use any naked flame such as lighters, matches, cigarettes etc.
- Page 12 Correct Wrong Correct Correct WALL FIXING • Before using the appliance, and in order to ensure safe use, be sure to fix the appliance to the wall using the chain and hooked screw supplied. Ensure that the hook is screwed into the wall securely WARNING! In order to prevent tipping of the appliance, this stabilizing devise must be used.
- Page 14 DESCRIPTION OF COOKER Symbols of functions on cooker: Closed Oven Burner Small flame Big flame Oven & grill burner Grill burner Manual operation Timer 1- Top lid (if fitted) 9- Oven door 2- Cooktop 10- Control knobs 3- Fascia panel 11- Bottom shelf...
- Page 15 4- Wire grid 12- Middle lower shelf 5- Tray 13- Middle upper shelf 6- Cavity 14- Top shelf 7- Bottom cover 15- Oven lamp (Option) 8- Door handle USING YOUR COOKER Before using your cooker please remove all flammable tapes, sytrofoam and any other materials in or on the cooker.
- Page 16 BURNER Burner cap Electronic Lighting Device USABLE SOUCEPAN DIAMETER Wok Burner Ø 24 - 28 cm Rapid Burner Ø 22 - 26 cm Semi-rapid Burner Ø 18 - 22 cm Auxiliary Burner Ø 12 - 18 cm...
- Page 17 Using the Gas Oven: Selection of the burner is indicated by symbol on the knob or on the fascia panel. Oven Burner Control: Push the knob in and turn in a counter-clockwise direction to the max. (+) symbol. To turn off, turn the knob in a clockwise direction until it stops.
- Page 18 Cooking Time Table: Meals Temperature (°C) Rack position Cooking time (min.) Creamed cake 150 - 170 30 - 35 Pastry 200 - 220 35 - 45 Biscuit 160 - 170 20 - 25 Cookie 160 – 170 20 - 35 Cake 160 - 180 25 - 35...
- Page 19 Oven Burner Nozzle Change: Remove the back panel of the cooker and remove the nozzle fixing body from the burner. Remove the nozzle from the injector body with a special screwdriver. After changing, close the nozzle with your finger, open the gas valve and check for any gas leak with soap foam around the nozzle- body connection surface.
- Page 20 Oven Burner 4,5 turns anticlockwise 4,5 turns clockwise Grill Burner 4 turns anticlockwise 4 turns clockwise IF THE APPLIANCE DOES NOT OPERATE Check the plug, socket and fuse box and There is no current No spark correct if there are any signs of tripping ignition.
- Page 21 USING THE HEAT SHIELD A safety panel (heat shield) is designed to protect the fascia panel and the control knobs when the oven is in Grill mode. Slot the heat shield under the fascia panel by opening the oven door. Then secure the heat shield in between the fascia panel and the oven door by gently closing the door.
- Page 22 Removing the Oven Door: Changing Oven Lamp: Let the oven cavity and grill burner or heating elements cool down. Switch off the electrical connection of your appliance before changing the lamp. Change with a 15-25W, 300 C˚ temperature resistant lamp.
- Page 23 PRODUCT FICHE 50x50 & 50x60 Free 60x60 Free Standing Gas Type : Standing Gas Cooker Cooker Cavity Number: Energy Source: Volume: 50 ltr 64 ltr Energy Consumption / Convection Mode (EC): 5,07 MJ/ 1,41kW 5,72 MJ / 1.59 kW Energy Efficiency Index (EEI): 88,48 90,08 Energy Class:...
- Page 25 Your 2 year Manufacturer’s guarantee THIS DOES NOT AFFECT YOUR STATUTORY RIGHTS. Your new Montpellier appliance carries a free guarantee which protects you against the cost of repairs during the first 24 months from date of purchase provided that: Any claim is accompanied by evidence of the model reference, model serial number and proof of purchase, such as a Sales Receipt, showing that the appliance was purchased within the 24 months prior to the date of claim.
- Page 26 Montpellier Domestic Appliances Ltd. Unit 1, Tewkesbury Retail Park, Northway Lane, Tewkesbury, Gloucestershire GL20 8JU www.montpellier-appliances.com The symbol on the product or on its packaging indicates that this product may not be treated as household waste. Instead it shall be handed over to the applicable collection point for the recycling of electrical and electronic equipment. By ensuring this product is disposed of correctly, you will help prevent potential negative consequences for the environment and human health, which could otherwise be caused by inappropriate waste handling of this product.
Need help?
Do you have a question about the SCG50W and is the answer not in the manual?
Questions and answers
The ignition spark on my montpellier eco cooker has stopped working. I lit one of the burners and when I went to light another straight after it did not work. The oven light is working fine.
Possible causes for the ignition spark not working on a Montpellier SCG50W eco cooker include:
1. Main gas valve is turned off – Turn it on.
2. Gas hose is bent – Connect the gas hose properly.
3. No gas supply – Check or replace the gas bottle (if LPG).
4. Burner injectors are clogged – Clean the injectors.
5. Burners are wet – Dry the burner parts carefully.
6. Burner caps are not fitted correctly – Ensure proper fitting.
If the issue persists, contact the service agent. Do not attempt repairs yourself.
