Summary of Contents for Harken Access Rail R27 LS
Page 1
R27 LS ACCESS RAIL ON METAL ROOFS Installation manual Range of INBRKT.XN brackets Translation of the Original Instructions Read the manual carefully before using the system. UINBRKT.XN-A 16-01-20...
Table of Contents Safety information ......................Page 4 Components ........................Page 5 INBRKT.X4 (STIFFENING BRACKET) ......................P INBRKT.X5 (END BRACKET) ........................P INBRKT.X6 (MIDDLE BRACKET) ......................P Features ..........................Page 8 FEATURES OF THE ANCHORING DEVICES AND BRACKET ASSEMBLY ........... Page 8 ANCHORING DEVICE FOR RAIL R27 LS + INBRKT.XN ................
SAFETY INFORMATION SAFETY INFORMATION WARNING! Before installing the product, carefully read the R27 LS access rail instruction manual. ENGLISH 16/01/2020...
(in this case there is no obligation to use rivets supplied by HARKEN as the sizing is done by an external designer). The situation described below refers to the field tests for connection between sandwich panel/corrugated sheet and the underlying structure.
FEATURES Figure 1 ANCHORING DEVICE TO RAIL R27 LS + INBRKT.XN The fall protection system consisting of the rail R27.LS + brackets for sandwich panel or corrugated sheet is: - Certified UNI 11578:2015 type D for use by 4 operators at the same time - Conforming to EN 795:2012 type D - Conforming to CEN/TS 16415:2013 type D for use by 4 operators at the same time.
FEATURES STANDARD INSTALLATION LAYOUT R27 LS + INBRKT.XN FALL PROTECTION SYSTEM Figure 2 Suitable for installation on horizontal or angled surfaces, wall or ceiling installation is not permitted. As for the installation surfaces, the user may work on both horizontal and angled roofs/work places. The linear anchoring device is used in a perpendicular direction to the rail, in the direction of the slope on the roof (Fig. 3).
Page 11
FEATURES The anchoring line to connect to is the rail R27 LS (Fig. 5), from which it is possible to work when using suitable PFPE (Personal Fall Protection Equipment) to protect from falling in restraint, work positioning and fall arrest. It is possible to connect to the rail directly using one or more trolleys in the Access Rail System series (see R27 Long Span Instruction Manual).
90° / 150°): do not tamper with or modify the finished Figure 9 element supplied by HARKEN. 4 fixing feet are required for each stiffening bracket. • Rail/Bracket FIXING KIT (Fig. 10) Figure 10 1 threaded insert INFIX1.LS.
Fixing bolts for assembling the fixing feet: required for component assembly. Do not use bolts or components Figure 12 other than those supplied by HARKEN. 4 bolts M12x25 in A2/70, with double washer and self- locking nut for connection between the ends of the diagonal ribs and the fixing feet on corrugated roofs.
HARKEN can supply remaining within the idea of standard fixing feet is in the range of 90° / 150°): do not tamper with or modify the finished element supplied by HARKEN. 5 fixing feet are required for each end bracket. Figure 17 16/01/2020...
Fixing bolts for assembling the fixing feet: required for component assembly. Do not use bolts or components Figure 19 other than those supplied by HARKEN. Figure 20 5 bolts M12x25 in A2/70, with double washer and self-locking nut for connection between the ends of the diagonal ribs or tie-rod plate and the fixing feet on corrugated roofs.
HARKEN can supply remaining within the idea of standard fixing feet is in the range of 90° / 150°): do not tamper with or modify the finished element supplied by HARKEN. 6 fixing feet are required for each middle bracket. Figure 25 16/01/2020...
Figure 27 component assembly. Do not use bolts or components Figure 28 other than those supplied by HARKEN. 6 bolts M12x25 in A2/70, with double washer and self-locking nut for connection between the ends of the diagonal ribs or tie-rod plate and the fixing feet on corrugated roofs.
INSTALLATION METHODS INSTALLATION ON CORRUGATED ROOFS OR SANDWICH PANELS Before fixing the anchoring devices to the sandwich panels or corrugated sheet, check that these supports comply with the minimum conditions set out in the table in the previous chapter. INSTALLING THE SEALS Remember that before proceeding with the installation of each device or element, apply the anti-infiltration seal supplied for each foot.
INSTALLATION METHODS END BRACKETS (CODE INBRKT.X5) Position the device on the profile crown of the corrugated roof: the standard tie-rod arm fixing foot must be installed above the sheet where the roof portions overlap, in the opposite direction to the starting direction of the rail, but on the same axis.
INSTALLATION METHODS MIDDLE BRACKETS (CODE INBRKT.X6) Position the device on the profile crown of the corrugated roof: the standard fixing feet do not have to be installed above the sheet where to roof portions overlap. Having positioned the device on the sandwich panel or corrugated sheet, check that the fixing feet adhere to the roof profile crown, i.e.
FEET ON REQUEST FEET ON REQUEST If the standard feet are not suited to the sandwich panel or corrugated sheet profile, special bends can be supplied on request, simply by providing the 4 measurements shown in the drawing (Fig. 33). Figure 33 Bmin Bmax ENGLISH...
