Air hAndling unit
KOMFORT EC S160
KOMFORT EC S160-E
KOMFORT EC SB160
KOMFORT EC SB160-E
KOMFORT EC S1 160
KOMFORT EC S1 160-E
KOMFORT EC S1B160
KOMFORT EC S1B160-E
KOMFORT EC S2B300
EN
USER'S MANUAL
KOMFORT EC S2B300-E
KOMFORT EC SB350
KOMFORT EC SB350-E
KOMFORT EC S1B350
KOMFORT EC S1B350-E
KOMFORT EC SB550
KOMFORT EC SB550-E
KOMFORT EC S2B550
KOMFORT EC S2B550-E
Advertisement
Table of Contents
Subscribe to Our Youtube Channel
Related Manuals for BLAUBERG KOMFORT EC S160
Summary of Contents for BLAUBERG KOMFORT EC S160
- Page 1 Air hAndling unit KOMFORT EC S160 KOMFORT EC S2B300-E KOMFORT EC S160-E KOMFORT EC SB350 KOMFORT EC SB160 KOMFORT EC SB350-E KOMFORT EC SB160-E KOMFORT EC S1B350 KOMFORT EC S1 160 KOMFORT EC S1B350-E KOMFORT EC S1 160-E KOMFORT EC SB550...
-
Page 2: Table Of Contents
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................7 Mounting and set-up .................................. 9 Connection to power mains ..............................14 Technical maintenance ................................ - Page 3 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de • While mounting the unit, avoid compression of the casing! Deformation of the casing may result in motor jam and excessive noise. • Misuse of the unit and any unauthorized modifications are not allowed. • Do not expose the device to adverse atmospheric agents (rain, sun, etc.). •...
-
Page 4: Purpose
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafes, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of intake air. -
Page 5: Technical Data
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for application with the ambient temperature ranging from +1 °C to +40 °C and relative humidity up to 80 %. In order to prevent condensation on the internal walls of the unit, it is necessary that the surface temperature of the casing is 2-3 °C above the dew point temperature of the transported air. - Page 6 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de MODEL Power supply voltage [V/50 (60) Hz] 1~ 230 Maximum unit power [W] Maximum unit current [A] 1.30 1.30 Maximum air capacity [m 3200 3230 Sound pressure level at 3 m distance [dBA] Transported air temperature [°С] -25...+40 Casing material painted steel...
-
Page 7: Design And Operating Principle
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE The unit has the following operating principle: Warm stale extract air from the room flows into the unit, where it is filtered by the extract filter, then air flows through the heat exchanger and is exhausted outside by the exhaust fan. Cold fresh air from the outside flows into the unit, where it is cleaned by the intake filter. - Page 8 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de UNIT OPERATION MODES Heat recovery Summer Cooling mode (only for the units with a bypass) Warm extract air from the room flows into the unit and is cleaned in The bypass damper is opened, the extract air that is removed the extract filter.
-
Page 9: Mounting And Set-Up
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de Reheating The process of supply air reheating by the EVH duct heater is described in the user’s manual for the control panel. For details, SUPPLY AIR SUPPLY AIR refer to the “Engineering menu”, “Additional options” and the “Heating control”... - Page 10 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de FS2 HUMIDITY SENSOR INSTALLATION AND CONNECTION (FOR S14 CONTROL PANELS) The FS2 humidity sensor is not included in the delivery set and can be ordered separately. Mounting of the FS2 sensor in the extract air duct The FS2 humidity sensor must be installed prior to unit mounting.
- Page 11 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de SERVICE SIDE CHANGE Make sure that the service panel provides sufficient access for maintenance and servicing. EXTRACT AIR EXHAUST AIR INTAKE AIR SUPPLY AIR SUPPLY AIR INTAKE AIR EXTRACT AIR EXHAUST AIR Left-handed modification Right-handed modification Service side change before unit mounting:...
- Page 12 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de UNIT MOUNTING To attain the best performance of the unit and to minimise turbulence-induced air pressure losses, connect the straight air duct section to the spigots on both sides of the unit while mounting. Minimum straight air duct length: •...
- Page 13 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de CONDENSATE DRAINAGE The KOMFORT EC S(1/2)(B) heat recovery units require condensate drainage. The hole for the drain pipe is at the bottom of the unit. Remove the plug from the hole, open the service panel and install the supplied drain pipe into the hole, then connect the drain pipe to the sewage system using the SFK 20x32 U-trap kit (available upon separate order).
-
Page 14: Connection To Power Mains
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. - Page 15 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de EXTERNAL WIRING DIAGRAM FOR S14 AUTOMATION re alarm panel Control Electric actuators (remove the jumper while connecting the contact) panel P1 of the external air dampers FS2 humidity sensor - Tx Rx + External supply exhaust device NO (CO2 sensor) L1 N...
- Page 16 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de EXTERNAL WIRING DIAGRAM FOR S19 AUTOMATION O ut +12V ELECTRIC SHOCK HAZARD c no +12V no c Р1 Designation Name Type Wire** CCU* DX-cooler 2 x 0.75 mm SМ1* Supply air damper actuator LF230 2 x 0.75 mm SМ2 * Extract air damper actuator LF230...
-
Page 17: Technical Maintenance
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de TECHNICAL MAINTENANCE BEFORE MOUNTING MAKE SURE THE CASING DOES NOT CONTAIN ANY FOREIGN OBJECTS (E.G. FOIL, PAPER). The unit must undergo technical maintenance 3 to 4 times a year. Maintenance includes general cleaning of the unit and the following operations: 1. - Page 18 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de TROUBLES AND TROUBLESHOOTING Trouble Possible reasons Troubleshooting Make sure the power supply line is connected correctly, No power supply. otherwise troubleshoot a connection error. Turn the unit off. Troubleshoot the motor jam and the The motor is jammed, the impeller blades are soiled. The fan(-s) does not start impeller clogging.
-
Page 19: Storage And Transportation Regulations
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 20 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de...
- Page 21 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de...
- Page 22 KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de...
-
Page 23: Acceptance Certificate
KOMFOrt EC S(1/2)(B)(-E) www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Air handling unit Model KOMFORT EC_______________ Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 24 www.blaubergventilatoren.de B106-1EN-09...
