- Page 1 Single-room air handling unit CIVIC EC LB 1200 V.2 CIVIC EC LBE 1200 V.2 CIVIC EC LBE2 1200 V.2 USER'S MANUAL...
-
Page 2: Table Of Contents
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de CONTENTS Safety requirements ..................................2 Purpose ........................................ 4 Delivery set ......................................4 Designation key ....................................4 Technical data ....................................5 Design and operating principle ............................7 Mounting and set-up .................................. 9 Connection to power mains ..............................15 Control ......................................... - Page 3 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de All operations described in this manual must be performed by qualified personnel only, properly trained and qualified to install, make electrical connections and maintain ventilation units. Do not attempt to install the product, connect it to the mains, or perform maintenance yourself. This is unsafe and impossible without special knowledge.
-
Page 4: Purpose
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de PURPOSE The unit is designed to ensure continuous mechanical air exchange in houses, offices, hotels, cafes, conference halls, and other utility and public spaces as well as to recover the heat energy contained in the air extracted from the premises to warm up the filtered stream of intake air. -
Page 5: Technical Data
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de TECHNICAL DATA The unit is designed for indoor application with the ambient temperature ranging from +1 °C up to +40 °C and relative humidity up to 60 % without condensation. In cold, damp rooms, there is a possibility of freezing or condensation inside and outside the casing. In order to prevent condensation on the internal walls of the unit, it is necessary that the surface temperature of the casing is 2-3 °C above the dew point temperature of the transported air. - Page 6 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de OVERALL DIMENSIONS [mm] 2106 2000 1110 1900 1951...
-
Page 7: Design And Operating Principle
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de DESIGN AND OPERATING PRINCIPLE UNIT OPERATION LOGIC Heat Recovery mode: warm stale extract air from the room flows into the unit, where it is filtered by the extract filters, then air flows through the heat exchanger and is exhausted outside by the extract fan. Cold fresh air from the outside flows into the unit, where it is cleaned by the supply filters. - Page 8 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de CIVIC EC LBE2 1200 V.2 unit design 13 14 15 1 – air dampers; 2 – G4 supply filter; 3 – F7 supply filter (option); 4 – preheater; 5 – supply fan; 6 – SETUP MODE button; 7 – louver shutters for adjusting supply air direction;...
-
Page 9: Mounting And Set-Up
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de MOUNTING AND SET-UP READ THE USER'S MANUAL BEFORE INSTALLING THE UNIT. While choosing the mounting location provide enough access for maintenance or repair work. Ø 425-450 min 950 The unit is designed for mounting to a horizontal surface adjacent to the wall with the ready-made holes for the air ducts. Lower the supports on the feet of the unit. - Page 10 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de Layout of holes for mounting screws (A – M6, B – M8) Remove the protective panels to access the bottom of the unit. At the end of the installation, install the panels in reverse order. Caution: Do not operate the unit with the panels removed.
- Page 11 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de Secure the sections with screw connections (mounting screws are included in the delivery set). Close the door and install the decorative panel.
- Page 12 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de , VOC, HUMIDITY SENSOR MOUNTING (NOT INCLUDED IN THE DELIVERY SET) The sensors are installed in the exhaust air duct upstream of the heat exchanger. Before installation, remove the protection plate and remove the extract filter. Install the CO2 and VOC sensors in the respective brackets and connect the connectors to them.
- Page 13 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de To connect the FS2 humidity sensor, unscrew the screws securing the bracket and remove it. Fix the FS2 humidity sensor with a screw on the bracket and connect the connector. Install the bracket with the sensor to the unit. To connect the DPWC112000 sensor, remove the connector from the cable and connect the cable to the sensor terminal according to the diagram.
- Page 14 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de CONDENSATE DRAINAGE The models without a drain pump are equipped with condensate drain pipes. Connect the drain system to the spigots. min 3 mm 1 – drain pipe (Ø 20 mm); 2 – coupling; 3 – L-shaped bend (Ø 20 mm); 4, 6 – connection pipe; 5 – U-trap; 7 – sewage system. A separate drainage system must be connected to each drain pipe.
-
Page 15: Connection To Power Mains
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de CONNECTION TO POWER MAINS POWER OFF THE POWER SUPPLY PRIOR TO ANY OPERATIONS WITH THE UNIT. THE UNIT MUST BE CONNECTED TO POWER SUPPLY BY A QUALIFIED ELECTRICIAN. THE RATED ELECTRICAL PARAMETERS OF THE UNIT ARE GIVEN ON THE MANUFACTURER’S LABEL. -
Page 16: Control
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de EXTERNAL CONNECTION DIAGRAM FOR CIVIC EC LB 1200 V.2 CCU* +24V 1~230 V/50 Hz (unit with a drain pump) PK1* Boost* 1~230 V/50(60) Hz (unit without a drain pump) EXTERNAL CONNECTION DIAGRAM FOR CIVIC EC LBE 1200 V.2, CIVIC EC LBE2 1200 V.2... -
Page 17: Technical Maintenance
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de TECHNICAL MAINTENANCE Maintenance operations of the unit are required 3-4 times per year. They include general cleaning of the unit and the following operations: 1. Filter maintenance. Dirty filters increase air resistance in the system and reduce supply air volume. -
Page 18: Troubleshooting
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de TROUBLESHOOTING IF UNIDENTIFIED NOISES OR ODOURS SHOULD ARISE AND IN CASE OF DEFORMATION OF ELEMENTS, VIBRATION, TERMINATION OF AIR SUPPLY/EXTRACTION OR REDUCED SYSTEM PERFORMANCE, IMMEDIATELY DISCONNECT THE UNIT FROM POWER SUPPLY AND CONTACT THE SELLER FOR THE UNIT DIAGNOSTICS DIAGNOSTICS MUST BE CARRIED OUT BY QUALIFIED SPECIALISTS Problem Possible reasons... -
Page 19: Manufacturer's Warranty
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de MANUFACTURER’S WARRANTY The product is in compliance with EU norms and standards on low voltage guidelines and electromagnetic compatibility. We hereby declare that the product complies with the provisions of Electromagnetic Compatibility (EMC) Directive 2014/30/EU of the European Parliament and of the Council, Low Voltage Directive (LVD) 2014/35/EU of the European Parliament and of the Council and CE-marking Council Directive 93/68/EEC. - Page 20 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de...
- Page 21 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de...
- Page 22 CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de...
-
Page 23: Certificate Of Acceptance
CIVIC EC LB(E)(2) 1200 V.2 www.blaubergventilatoren.de CERTIFICATE OF ACCEPTANCE Unit Type Single-room air handling unit Model Serial Number Manufacture Date Quality Inspector’s Stamp SELLER INFORMATION Seller Address Phone Number E-mail Purchase Date This is to certify acceptance of the complete unit delivery with the user’s manual. The warranty terms are acknowledged and accepted. - Page 24 www.blaubergventilatoren.de B142-1EN-03...
